HydroTap
(See page 29,30,33 for Command-Centre
1.1
All thread rod
Black plastic
spacer
Spider
clamp
Nut
1.2
Apply a light smearing of silicon sealant on the underside of the spacer to ensure a
watertight fit.
Note make sure the tap location will allow
the tap spout to drain into the sink.
Page 12 of 40
G4 - Tap installation
®
connections).
TM
Stainless steel
spacer
Cut a
35mm hole in the worktop / sink.
Ø
Ø35mm
802005UK - Residential (Boiling),chilled and sparkling installation instructions - Aug 2015 - v2.01
Clearance envelope
