Installation Instructions

Minimum Tool and Equipment List

RMD5000 Rackmount Kit Instructions
This section contains the procedures needed to rackmount a DPO4000B,
MSO4000B, DPO5000, or MSO5000 series instrument.
The following tools are required to attach the rack-adapter kit hardware, install
cabling hardware, and mount the rack-adapted instrument into a standard
equipment cabinet. All tools are standard tools that are readily available.
Table 4: Tools required for rackmount installation
Name
Screwdriver handle
(magnetic)
No. 2 Phillips or
PoziDriv tip
T-10 TORX tip
T-15 TORX tip
T-20 TORX tip
1/4-inch wrench
Torque driver
These instructions are for qualified service personnel who are familiar with
servicing the product. If you need further details for disassembling or reassembling
the product, refer to the appropriate product manual. Contact your nearest
Tektronix Service Center or Tektronix Factory Service for installation assistance.
WARNING.
To prevent the rackmounted instrument from tipping forward onto the
operator, install the instrument so that the operator will be able to access all of its
rear-panel connectors without pushing down on the instrument.
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
WARNING.
To avoid electric shock, disconnect the power cord from the mains
power before removing the cover. Failure to do so could result in personal injury
or death.
Description
Accepts 1/4-inch hexagonal head driver tips
Phillips or PoziDriv-driver tip for number 2 size screw heads
TORX-drive tip for T-10 size screw heads (flat-head)
TORX-drive tip for T-15 size screw heads
TORX-drive tip for T-20 size screw heads
Wrench or nut driver can be used to install slides
6.5 in long shaft; accepts 1/4-inch hexagonal head driver tips
Installation Instructions
7
