Installation Instructions
WARNING.
To ensure that the rackmount track locks, make sure the track button
latches are oriented correctly: the right-side latch is located toward the bottom
of the rackmount panel and the left-side latch is located toward the top of the
rackmount panel. (See Figure 12.) If the button latches are not oriented correctly
the instrument could slide from the rack, which could cause personal injury or
damage to the instrument.
Figure 12: Track orientation
This completes the installation of the slide hardware to the instrument. To
complete the installation, proceed to: Rackmount the Rack- Adapted Instrument.
(See page 16.)
