Installation Instructions

Minimum Tool Equipment List
SPG600 Sync Pulse Generator Rackmount Instructions
This section provides instructions for installing the SPG600 Sync Pulse
Generator into a standard 19-inch equipment rack.
The following tools are required to install the rackmounting hardware into the
equipment rack. All tools are standard tools that are readily available.
Required tools and equipment
Screwdriver handle (magnetic)
#2 Phillips tip
#2 Pozidriv tip
WARNING. To prevent the rackmounted instrument from tipping forward onto the
operator, install the instrument so that the operator will be able to access all of
its rear- -panel connectors without pushing down on the instrument.
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
Description
Accepts 1/4 inch hex-head driver tips
Philllips-driver tip for M3 size screw heads
Pozidriv-driver tip for #2 size screw heads
