Verify Output - Cypress CY8CKIT-042-BLE User Manual

Table 4-2. UART Pin Assignment for RS232 Voltage Translator
UART Pins
RX
TX
RTS
CTS
4.6.3

Verify Output

1. Connect the BLE Pioneer Kit through the USB connector J13.
2. Program the BLE Pioneer Kit with the PSoC_4_BLE_DTM or PRoC_BLE_DTM project, depend-
ing on the module used (PSoC 4 BLE or PRoC BLE), as described in
page 41. Programming should complete successfully.
3. Connect the Serial link, UART or RS232 to the tester.
4. On the software tool for tester, configure the UART communication with the correct COM port and
baud rate, as set in the BLE Component.
5. Start the test. The tool will generate the report after the end of the test. This depends on the tes-
ter/tool being used.
