Cypress CY8CKIT-064B0S2-4343W Manual

Psoc 64 secure boot wi-fi bt pioneer kit
Hide thumbs

Advertisement

Quick Links

Download this manual
Please note that Cypress is an Infineon Technologies Company.
The document following this cover page is marked as "Cypress" document as this is the
company that originally developed the product. Please note that Infineon will continue
to offer the product to new and existing customers as part of the Infineon product
portfolio.
Continuity of document content
The fact that Infineon offers the following product as part of the Infineon product
portfolio does not lead to any changes to this document. Future revisions will occur
when appropriate, and any changes will be set out on the document history page.
Continuity of ordering part numbers
Infineon continues to support existing part numbers. Please continue to use the
ordering part numbers listed in the datasheet for ordering.
www.infineon.com
Arrow.com.
Downloaded from

Advertisement

loading
Need help?

Need help?

Do you have a question about the CY8CKIT-064B0S2-4343W and is the answer not in the manual?

Questions and answers

Related Manuals for Cypress CY8CKIT-064B0S2-4343W

Summary of Contents for Cypress CY8CKIT-064B0S2-4343W

  • Page 1 Please note that Cypress is an Infineon Technologies Company. The document following this cover page is marked as “Cypress” document as this is the company that originally developed the product. Please note that Infineon will continue to offer the product to new and existing customers as part of the Infineon product portfolio.
  • Page 2 PSoC 64 “Secure CY8CKIT-064B0S2-4343W Boot” Wi-Fi BT Pioneer Kit Guide CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide Document Number: 002-29286 Rev. *E Cypress Semiconductor An Infineon Technologies Company 198 Champion Court San Jose, CA 95134-1709 www.cypress.com www.infineon.com Arrow.com.
  • Page 3 High-Risk Device whose failure to perform can be reasonably expected to cause, directly or indirectly, the failure of the High-Risk Device, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from any use of a Cypress product as a Critical Component in a High-Risk Device.
  • Page 4 5.2.4 Serial Interconnection Between PSoC 5LP and CYW4343W ......47 5.2.5 Power Supply System ..................47 5.2.6 I/O Headers....................51 5.2.7 CapSense Circuit ...................52 5.2.8 LEDs ......................53 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 5 5.3.5 U.FL (UMCC) Connector for External Antenna ..........58 5.3.6 U.FL (UMCC) Connector for Antenna Diversity..........58 Bill of Materials ......................59 Frequently Asked Questions..................59 Revision History CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 6 The end-of-life cycle for this kit is five years from the date of manufacture mentioned on the back of the box. Contact your nearest recycler to discard the kit. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 7 After removing the board from its box, place it on a grounded, static-free surface. Use a conductive foam pad, if available. Do not slide the board over any surface. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com.
  • Page 8 - Getting Started with PSoC 6 MCU on ModusToolbox to help you familiarize with the PSoC 6 MCU and help you create your own design using the ModusToolbox software. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 9 ■ Figure 1-1. Kit Contents Inspect the contents of the kit; if you find any part missing, contact your nearest Cypress sales office for help: www.cypress.com/support. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com.
  • Page 10 CapSense touch sensing slider (5 elements) and two buttons. The slider and buttons are capable ■ of using self-capacitance (CSD) or mutual-capacitance (CSX) sensing methods. A second Micro-B connector for USB device interface ■ CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 11 A microSD Card holder ■ Figure 1-2 shows the pinout of the Board. Figure 1-2. PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Board Pinout CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 12 P6[1] I2C SDA Arduino (J3.9) Remove R59 to disconnect from KitProg3. P6[2] USB VBUS Detect – – P6[3] USB Interrupt – – CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 13 GPIO on non-Arduino Remove R31 to disconnect from CapSense. header IO13 (J21.6) Populate R151 to connect to GPIO on non- Arduino header. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 14 – (LED9) header (J24.4) P11[2] QSPI Flash CS – – P11[3:6] QSPI Flash IO[3:0] – – P11[7] QSPI Flash CLK – – CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 15 BT_UART_TXD UART interface with – – Host MCU (PSoC 64 device) BT_UART_RXD UART interface with – – Host MCU (PSoC 64 device) CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 16 Displays file locations, user entered text, and source code: Courier New C:\...cd\icc\ Displays file names and reference documentation: Italics Read about the sourcefile.hex file in the PSoC Creator User Guide. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 17 Integrated Development Environment Internet of Things Light-emitting Diode Low Power Oscillator Personal Computer Pulse Density Modulation PSoC Programmable System-on-Chip Pulse Width Modulation CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 18 Serial Peripheral Interface SRAM Serial Random Access Memory Serial Wire Debug UART Universal Asynchronous Receiver Transmitter Universal Serial Bus Watch Crystal Oscillator CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 19 ~/.bash_profile  Make sure that you have the latest version of pip installed, use the following command python -m pip install --upgrade pip CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 20 From the README.md file: How to install libusb depends on your OS: macOS: use Homebrew: brew install libusb ❐ Linux: should already be installed. ❐ CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 21 2048 KB + 32 KB + 32 KB 8 KB cache for each CPU SRAM0 512 KB SRAM1 256 KB SRAM2 256 KB 64 KB CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 22 Monitoring Translator Carrier  VDDIO0 WL_UART TX, RX, KP_GPIO_0 Module microSD Card  VDDIO0 Slot I2C EEPROM 3.3V, VTARG PSoC 64 Device  KP_VBUS I/O Headers  (Arduino) 2 x CapSense Buttons,  1 x 5‐segment  PSoC 64 Device  CapSense Slider I/O Headers  (Non Arduino) USB Host & Device CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 23 Pioneer Board. Figure 3-4. PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Board - Top View 34 17 16 17 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 24 8. PSoC 64 VDDIO0 current measurement jumper (J19): An ammeter can be connected to this jumper to measure the current consumed by the PSoC 64 VDDIO0 power domain. This is not loaded by default. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 25 25. PSoC 64: This kit is designed to highlight the features of the PSoC 64 device. For details on PSoC 64 pin mapping, refer to Table 1-1 on page CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 26 37. microSD Card holder (J20): Provide SDHC interface with microSD cards with the option to detect the presence of the card. Hardware Functional Description on page 40 for details on various hardware blocks. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 27 The PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Board can be programmed and debugged using the onboard KitProg3. KitProg3 is a programmer/debugger with USB-UART and USB-I2C functionality. A Cypress PSoC 5LP device is used to implement KitProg3 functionality. For more details on the KitProg3 functionality, see the KitProg3 User Guide.
  • Page 28 Figure 3-8. UART Connection between KitProg3 and CYW4343W For more details on the KitProg3 USB-UART functionality, see the KitProg3 User Guide. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 29 Figure 3-9. I2C Connection between KitProg3 and PSoC 64 Chip KitProg3 PSoC 64 P6_VDD R133 R134 4.7K 4.7K KP_I2C_SDA P6[1] P6[0] KP_I2C_SCL CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 30 Boot&Upgrade Policy Boot&Upgrade Policy Debug Policy Debug Policy Signed by Dev Rot Key Signed by Dev Rot Key prov_req.JWT prov_req.JWT CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 31 Sign images example.hex Signed, Boot image(Slot#0) Sign images Encrypt Upgrade example_enc_upgrade.hex Image Encrypted & Signed, Upgrade Image(Slot#1) “CySecureTools” API Encrypt = Yes CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 32 1. Open the Eclipse IDE for ModusToolbox and create a new application. Figure 4-3. Create New Application 2. Select the CY8CKIT-064B0S2-4343W target and click Next. Figure 4-4. CY8CKIT-064B0S2-4343W Target Selection CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 33 Once creation is done, click Close to close the window and import the project into the Eclipse IDE. Figure 4-5. “Secure Blinky LED FreeRTOS” Example Selection CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 34 “Secure Boot” SDK user guide. Figure 4-6. Project Workspace having a new ‘policy’ directory CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 35 (if encrypt is enabled) generated according to the policy. These keys are used either to sign (or) encrypt images built by ModusToolbox software. Figure 4-7. Project Workspace having a new ‘keys’ directory CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 36 Failing the entrance exam returns an error in the command line. If there is any firmware running on the device, existing firmware can be erased using the tools like Cypress Programmer. Run the below command: CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 37 “CySecureTools” allow re-provisioning. Note that the Entrance Exam is not run during a re-provisioning process. cysecuretools --target cyb06xxa --policy ./policy/ policy_single_CM0_CM4_swap.json re-provision-device CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 38 This post-build script uses the policy file to find the private key path used to sign the application. If a different/invalid key is used then the “Secure Boot” process will fail. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com.
  • Page 39 Note: if you open the terminal after programming the kit, just press/release the reset button to see the message on the terminal window. Figure 4-11. UART Output CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 40 2. If you want to create new keys and policies, please follow the re-provisioning note provided in Section 4.3, step 5. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 41 VCCD VDDIO2 VCCD VDD_NS VDD_NS 6.3V VDDUSB VSS0 VDDUSB VSS1 VSS2 VBACKUP VBUCK VCCD VSS3 VSS4 VBACKUP VSS5 0 OHM CY B0644ABZI-S2D44 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 42 VBACKUP 10uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 6.3V 6.3V 6.3V 6.3V VDDA VDDUSB VDD_NS 10uF 0.1uF 0.1uF 0.1uF 10uF 0.1uF 6.3V 6.3V CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 43 VBAT VBAT GND1 GND2 VDDIO_WL GND3 GND4 GND5 GND6 GND7 2.2uH GND8 SR_VLX GND9 GND10 GND11 GND12 VIN_LDO GND_SR_PVSS1 4.7uF GND_SR_PVSS2 LBEE5KL1DX-883 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 44 0 OHM 0 OHM Note: VDDUSB is used as this is the only fix ed 3.3V rail VBAT is prov ided as optional CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 45 WL_IO_2 BT_IO_2 BT_GPIO_3 BT_IO_3 BT_GPIO_4 WL_JTAG_TCK BT_IO_4 BT_GPIO_5 WL_JTAG_TMS BT_IO_5 WL_JTAG_TRST_L WL_JTAG_TDI RFU_1 WL_JTAG_TDO RFU_2 WL_JTAG_SEL WL_JTAG_SEL LPO_IN EXT_LPO Carrier Module Footprint CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 46 .3B*3,2B 3>@ 3>@ 3/3B9'' 9'',2 9'',2 3/3B9'' 3/3B9'' 3/3B9&&' .3B*3,2B 8$57BB576 86%B9B6(16( 8$57BB7; 97$5*B0($6 8$57BB5; & .3B86%B'3 .3B86%B'0 'HO6LJ %\SDVV &DSDFLWRU 8$57BB5; CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 47 R115 0 OHM 74LVC1T45DW-7 No Load 0.1uF 0.1uF 0 OHM VCCA VCCB B_UART_1_CTS ARD_D2 UART_1_CTS B_UART_1_CTS 0 OHM B_UART_1_RTS ARD_D3 100K 74LVC1T45DW-7 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 48 100K 10nF RCLAMP0854P.TCT 10nF RCLAMP0854P.TCT 0.1uF 0.1uF Power Supply 'OR'ing USB_Hold USB_Hold VCC_IN JMP1 PMEG3020BEP JMP2 KP_VBUS PMEG3020BEP P6_VBUS PMEG3020BEP No Load CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 49 2.5V w hen removed. VCC_1V8 1.8V Voltage Regulator VCC_IN 4.7uH 1.8V 600mA 10nF 10uF 0.1uF 47pF 40.2K 22uF 10uF 0.1uF PMEG3020BEP AOZ1280CI B_KP_PMIC_EN 32.4K CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 50 Figure 5-8. Voltage Selection VDDIO0 Voltage Selection VCC_3V3 VCC_VDDIO0 VCC_1V8 0 OHM 0 OHM No Load CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 51 Note: When measuring P6_VDD current, make sure that the J25 jumper shunt is removed. This will disconnect the potentiometer from VDDA and removes the leakage caused by it. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com.
  • Page 52 5B/('B/ 5*%B*B/('B/ %7B,6B', %7B8$57B576 ,2 5*%B%B/('B/ %7B*3,2B :/B8$57B5; %7B*3,2B :/B8$57B7; &21 [ %7B*3,2B :/B*3,2B 1R /RDG %7B*3,2B :/B*3,2B &21 [ 1R /RDG CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 53 Simultaneous GPIO switching with unrestricted drive strengths and frequency can affect CapSense and ADC performance. For more details, see the Errata section of the corresponding device datasheet. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 54 P6_VDD_BUF KitProg3 Status LED 100K P5LP1_4 750 OHM LED2 Y ELLOW P1_1 RGB_R P0_5 RGB_G P7_3 RGB_B P1_5 LED_1 P11_1 LED 2 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 55 FLASH_SS_L No Load R138 0 OHM FLASH_INT_L FLASH_INT_L No Load VCC_VDDIO0 VCC_FLASH VCC_IO_FLASH VCC_FLASH 0 OHM VCC_IO_FLASH 0.1uF 0.1uF 0 OHM TP20 CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 56 Note: Load R165, R167 and R169 and remove R162, R163, R164, R166 and R168 to change from SDHC to SPI interface for microSD card CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 57 P6_VDD current. Figure 5-18. Schematics of Potentiometer VDD_POT Potentiometer HDR2 VDDA VDD_POT 3386P-1-103TLF 0 OHM ARD_A6 R170 0 OHM No Load 0.1uF CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 58 Figure 5-21. microSD Card Detect Multiplexing Card Detect Multiplexing R159 0 OHM ARD_D12 No Load PAD_SD_CD_L R161 0 OHM SD_CD_L R160 0 OHM IO16 No Load CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 59 0 OHM 0 OHM Note: VDDUSB is used as this is the only fix ed 3.3V rail VBAT is prov ided as optional CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 60 Any kind of overlays (up to 5-mm thickness) like wood, acrylic, and glass can be used with CapSense. Note that additional tuning may be required when the overlay is changed. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com.
  • Page 61 Note: If R130 is loaded and external power is used, make sure to remove jumper shunt from J14 to prevent reverse voltage to on-board regulator CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 62 “Board Details” on page Updated description. Updated Figure 1-2. Updated Table 1-1. Updated “Additional Learning Resources” on page Updated hyperlinks. Updated description. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 63 “Build and Program the Example Project” on page Updated description. Updated Figure 4-8. Updated Figure 4-9. Updated “Additional Code Examples” on page Updated description. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 64 “PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Rework” on page Updated “microSD Card SPI Multiplexing” on page Updated Figure 5-22. Updated “Frequently Asked Questions” on page Updated description. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
  • Page 65 Updated the relevant content for latest version of the ModusToolbox 2.3.1. Updated Schematics. Updated the Title and secure terminology across the document. CY8CKIT-064B0S2-4343W PSoC 64 “Secure Boot” Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E Arrow.com. Downloaded from...
