A.6

Migrating projects across different Pioneer series kits

All Cypress Pioneer series kits are Arduino Uno compatible and have some common on-board
peripherals such as RGB LED, CapSense and User Switch. However, the pin mapping in each of the
boards is different due to differences in pin functions of the PSoC device used. This guide lists the
pin maps of the Pioneer series kits to allow for easy migration of projects across different kits.
In some cases, the pins available on the Pioneer kit headers are a superset of the standard Arduino
Uno pins. For example J2 contains only 1 row of pins on the Arduino Uno pinout while it contains 2
rows of pins on many of the Pioneer series kits.
Figure A-25. Pioneer series kits pin map
10
Arduino compatible
power header
CY8CKIT-042-BLE Bluetooth® Low Energy (BLE) Pioneer Kit Guide, Doc. # 001-93731 Rev. *C
8
1
J3
J4
Pioneer series kits
2
J1
8 1
1
CY8CKIT-040
6x1 header
CY8CKIT-042-BLE
6x2 header
CY8CKIT-042 & CY8CKIT-044
9x2 header
1
Arduino compatible
12
18
J2
17
11
I/O headers
