Item Qty Reference
22 1 J14
23 1 J15
24 1 J16
25 1 LED1
26 1

LED2

27 1 LED3
28 3 L1,L2,L3
29 3 Q2,Q4,Q6
30 1 Q1,
31 2 Q3,Q5
32 1 R1
33 1 R2
34 1 R3
35 1 R4
36 1 R5
37 1 R6
R19,R26,R27,R3
6,R37,R38,R45,R
38 14
46,R47,R52,R53,
R54,R55,R56
39 2 R8,R58
40 2 R9,R20
41 1 R10
42 1 R11
43 2 R13,R14
44 2 R15,R16
45 2 R17,R18
134
Value Description
CONN RCPT 1POS .100"
1X1 RECP
SNGL HORZ
CONN HEADR BRKWAY
2p_jumper
.100 2POS STR
CONN HEADR BRKWAY
3p_jumper
.100 3POS STR
Power LED LED 595NM AMB DIFF
Amber 0805 SMD
Status LED LED GREEN CLEAR 0805
Green SMD
LED RED/GREEN/BLUE
RGB LED
PLCC4 SMD
330 OHM @ FERRITE CHIP 330 OHM
100MHz 0805
MOSFET P-CH 30V 2.2A
PMOS
SOT23
MOSFET P-CH 30V 3.8A
PMOS
SOT23-3
MOSFET P-CH 20V 3.5A
PMOS
SOT23
RES 11K OHM 1/10W 1%
11K 1%
0603 SMD
RES 560 OHM 1/8W 5%
560 ohm
0805 SMD
RES 14.7K OHM 1/10W
14.7K 1%
1% 0603 SMD
RES 10K OHM 1/10W 1%
10K 1%
0603 SMD
RES 4.3K OHM 1/10W 1%
4.3K 1%
0603 SMD
RES 100K OHM 1/10W 5%
100K
0402 SMD
RES 0.0 OHM 1/10W 0603
ZERO
SMD
RES 15K OHM 1/10W 1%
15K
0603 SMD
RES 10K OHM 1/8W 1%
10K 1%
0805 SMD
RES 10K OHM 1/10W 5%
10K
0603 SMD
RES 820 OHM 1/8W 5%

820 ohm

0805 SMD
RES 0.0 OHM 1/8W 0805
ZERO
SMD
RES 22 OHM 1/10W 1%
22E
0603 SMD
RES 15K OHM 1/10W 5%
15K
0603 SMD
CY8CKIT-042-BLE Bluetooth® Low Energy (BLE) Pioneer Kit Guide, Doc. # 001-93731 Rev. *C
Manufacturer Mfr Part Number
Samtec Inc BCS-101-L-S-HE
Protectron Electro-
P9101-02-12-1
mech
Protectron Electro-
P9101-03-12-1
mech
Avago Technolo-
HSMA-C170
gies
Chicago Miniature CMD17-21VGC/TR8
CLV1A-FKB-
Cree, Inc.
CJ1M1F1BB7R4S3
Murata BLM21PG331SN1D
ON Semiconductor NTR4171PT1G
Diodes Inc DMP3098L-7
NXP Semiconduc-
PMV48XP,215
tors
Panasonic - ECG ERJ-3EKF1102V
Panasonic - ECG ERJ-6GEYJ561V
Panasonic - ECG ERJ-3EKF1472V
Panasonic - ECG ERJ-3EKF1002V
Panasonic - ECG ERJ-3EKF4301V
Panasonic - ECG ERJ-2GEJ104X
Panasonic - ECG ERJ-3GEY0R00V
Panasonic - ECG ERJ-3EKF1502V
Stackpole Electron-
RMCF0805FT10K0
ics Inc
Panasonic - ECG ERJ-3GEYJ103V
Panasonic - ECG ERJ-6GEYJ821V
Panasonic-ECG ERJ-6GEY0R00V
Panasonic - ECG ERJ-3EKF22R0V
Panasonic - ECG ERJ-3GEYJ153V
