Analog soft‐clipper prevents A/D converter overload without loss of dynamic range.
Line Bit Rates (ISDN)
•
56 or 64kbps per channel, front panel selectable.
Bit Rates (V.35/X.21)
•
56, 64, 112 (imuxed), 128 (imuxed), 96, 128, 256, 384 kbps front panel selectable.
Receive Output
•
Active differential.
•
Level: Front panel selectable for ‐10 or +4dBu, nominal.
•
Impedance: < 33 (x2)
•
XLR male
AES/EBU Digital I/O (non‐mixer version only)
•
Sample rates supported: 32, 44.1 and 48kHz
•
Rate conversion: Input and output independently selectable. Can be bypassed.
•
Input clock: From external source or Telco clock.
•
Output clock: From transmission sample rate, external source, or AES/EBU input.
Inverse Multiplex/Demultiplex
Internal channel splitting/combining of two network channels for stereo modes.
•
AAC: Telos Zephyr™ protocol.
•
AAC‐LD: Telos Zephyr™ protocol.
•
Layer‐3: FHG/Telos Zephyr™ (Buchta) protocol.
•
Layer‐2: CCS CDQ™ protocol compatible.
Optional V.35/X.21 Direct Digital Interface
•
Two ports, both V.35/X.21. Automatically selected when the appropriate cable is
connected.
ISDN Interface
•
Compatible with National ISDN, AT&T 5ESS custom, Northern Telecom DMS‐100
custom, Siemens EWSD, INS 64(Japan) and EURO‐ISDN (ETS‐300). Compatibility and
approval pending in some countries; contact Telos for current status.
LAN Interface
•
100Base‐T Ethernet port using RJ‐45 connector. Full Duplex Supports TCP/IP (HTML,
Telnet and FTP).
ISDN Voice Telephone Mode
•
Two channels using G.711 standard, µ‐Law or A‐Law. 300–3,400Hz. DTMF signaling
provided (CCITT standard).
Remote Control and Ancillary Data
•
RS‐232 9‐pin D‐Sub female (DCE): Asynchronous; 8 data, no parity, 1/2 stop, 2400‐
57,600 bps.
•
100Base‐T Ethernet port using RJ‐45‐style connector using Telnet or web browser
(HTML).
