8. Control

The electrochemical sensors for gas analysis are submitted to a wearing process and do
age. They alter their output values along the time depending on the gas concentration, the
exposure time and the soiling grade of the sampled gas.
The program monitors the sensors and corrects drifts. But if the drifts and the correlated
measurement errors increase, an error message is displayed. In this case the corresponding
sensor must be changed by an authorized service centre.
The control menu informs about the current status values for the sensors. Further
information is also consigned on 3 display pages (use cursor keys to scroll)
The following status values are available:
- battery voltage (charging status); is displayed as a symbol in all menus:
1
Full charge
Page 50
1
2
Half charge
Parameter
[Sensor] #### mV
Akku #,## V
Operation hours:
Total:
Next unit check:
Service tel.:
Parameter
Program version:
Serial no.:
CO purges:
Error counter:
Parameter
Last service (history)
2
Meaning
Output voltage of the sensor
Output voltage of the battery
Operation hours since last service
Total operation hours
Date of the next recommended service
Phone number of the next service center
Meaning
Software version
Serial number of the instrument
Amount of CO switch-offs
Amount of errors
Meaning
Collection of the last maintenance
3
3
Empty
