1.2. Control module

Connection air
temperature
Keyboard control module
Measurement
values record-
ing
Cursor keys
(Up/Down/Right/
Left/Scroll)
ESC key
(quit/
escape menu)
Switch ON/OFF
control module
Page 6
Function keys
(function shown on display)
In the input mode,
the keys are used
for numerical inputs
Slot for Multi-
Media-Card
Socket for connection
ecom-J2KN
Graphics
display
Connection
USB
Connection
keyboard
cable by wire
transfer basic
Display
backlit
ON/OFF
OK key
(confirm selec-
tion)
Print key
(access to
printing menu)
