3. Carry out gas analysis

If the calibration has been successfully completed and all previous queries have been
answered, the instrument is ready for operation.
Hint
The following minimum times must be observed in order to obtain correct
measured values:
- 1 minute for fresh air calibration of the sensors
- 2 minutes for stable measured values at the instrument
Hint
To obtain accurate measurement values it's important to re-calibrate the
instrument after each measurement (at the latest after one hour)!
- Switch off the instrument and wait for the switch off phase
- Switch on the device and refer to chapter "2. Measurement Preparations".
The current measured values of the active sensors are displayed in the measurement menu.
In addition, various measuring procedures are available:
Display
Gas analysis 1
Gas analysis 2
Gas analysis 3
CO measurement
O2 Check
Draught
measurement
Flow measurement
Hint
For a detailed description of the individual measuring procedures, see the
following sections.
ecom-EN3
To calibrate the sensors, proceed as follows:
Meaning
Display of 4 definable measured values
Display of 4 definable measured values
Display of 8 definable measured values
Display of 4 measured values for testing CO with O2 reference
Display of 3 measured values for testing the O2 in combustion air
Display of the measured value Draught / Pressure and storing a
reference value
Display of 3 measured values for testing the flow inside an exhaust
pipe
Comment
Select the measured values with the <F4>
key
Select the measured values with the <F4>
key
Select the measured values with the <F4>
key
Gas path check
Set the zero point of the pressure sensor
with the <F4> key
While this measurement procedure is
active, the gas pump remains inactive
Set the zero point of the pressure sensor
with the <F4> key
Storing a reference value with <save>
Set the zero point of the pressure sensor
with the <F4> key
Enter the cross-section in the exhaust pipe
with the <F1> key
