Model Configuration and Combination

Number of units and capacity of connectable indoor units
Standard Equivalent output
series
R-22 VRV PLUS series system model
Outdoor unit combination
Total number of connectable indoor units
Total capacity of connectable indoor units
Standard Equivalent output
series
R-22 VRV PLUS series system model
Outdoor unit combination
Total number of connectable indoor units
Total capacity of connectable indoor units
Y1 : 3 phase, 380~415V, 50Hz
YAL : 3 phase, 380V, 60Hz
(E) : Salt damage resistant specifications
Connectable indoor unit
Indoor unit
Ceiling 2-way blow FXYC20KVE·25KVE·32KVE·40KVE·50KVE·63KVE·80KVE·125KVE
mounted
4-way blow FXYF25KBVE·32KBVE·40KBVE·50KBVE·63KBVE·80KBVE·100KBVE·125KBVE
cassette unit
Corner type FXYK25KV1/VAL·32KV1/VAL·40KV1/VAL·63KV1/VAL
Ceiling mounted low silhoutte duct FXYD20KAVE·25KAVE·32KAVE·40KAVE·50KAVE·63KAVE
unit
Concealed ceiling unit FXYS20KV1/VAL·25KV1/VAL·32KV1/VAL·40KV1/VAL·50KV1/VAL·63KV1/VAL·80KV1/VAL·100KV1/
VAL·125KV1/VAL
Concealed ceiling unit FXYB20KV1·25KV1·32KV1·40KV1·50KV1·63KV1·80KV1·100KV1·125KV1·
Concealed ceiling unit (large) FXYM40KVE·50KVE·63KVE·80KVE·100KVE·125KVE·200KJVE·250KJVE
Ceiling suspended unit FXYH32KVE·63KVE·100KVE
Wall mounted unit FXYA25KVE·32KVE·40KVE·50KVE·63KVE
Floor standing unit FXYL20KJVE·25KJVE·32KJVE·40KJVE·50KJVE·63KJVE
Concealed floor standing unit FXYLM20KJVE·25KJVE·32KJVE·40KJVE·50KJVE·63KJVE
VE : 1 phase, 220~240V/220V, 50/60Hz
V1 : 1 phase, 220~240V, 50Hz
VAL : 1 phase, 220V, 60Hz
Indoor unit capacity
New refrigerant model code 20 type 25 type 32 type 40 type 50 type 63 type 80 type 100 type 125 type 200 type 250 type
Selecting model capacity 2.2kW
Equivalent output 0.8HP
Use the above tables to determine the capacities of indoor units to be connected. Make sure the total
capacity of indoor units connected to each outdoor unit is within the specified value (kW).
The total capacity of connected indoor units must be within a range of 50 to 130% of the rated capacity
of the outdoor unit.
In some models, it is not possible to connect the maximum number of connectable indoor units. Select
models so the total capacity of connected indoor units conforms to the specification.
General Information
16HP 18HP
RSXY16KAY1(E)/ RSXY18KAY1(E)/
YAL(E) YAL(E)
Main unit RXY8KAY1(E)/ RXY10KAY1(E)/
YAL(E) YAL(E)
Sub unit RXE8KAY1(E)/ RXE8KAY1(E)/
YAL(E) YAL(E)
Up to 20 units
200~520 225~585
26HP
RSXY26KAY1(E)/
YAL(E)
Main unit RXY16KAY1(E)/YAL(E)
Sub unit RXE10KAY1(E)/YAL(E)
325~845
Model name
2.8kW 3.5kW 4.5kW 5.6kW 7.0kW
1HP 1.25HP 1.6HP 2.0HP 2.5HP
