SiE33-102

4.12 Indoor Field Setting

Making a field setting
Field settings must be made by remote control if optional accessories have been installed on the indoor
unit, or if the indoor unit or HRV unit's individual functions have been modified.
4.12.1 Wired Remote Control <BRC1A61(51)>
1. When in the normal mode, push the
the "field set mode."
2. Select the desired "mode No." with the
3. During group control and you want to set by each individual indoor unit (when mode No. 20, 21, 22, 23,
25 has been selected), push the time mode
Note: This operation is not required when setting as a group.
4. Push the
5. Push the
6. Push the timer
7. Push the
(Example)
When setting the filter sign time to "Filter Dirtiness-High" in all group unit setting, set the Mode No. to "10",
Mode setting No. to "0" and setting position No. to "02".
General Information
button for 4 seconds or more, and operation then enters
button.
button and select the "indoor unit No." to be set.
button and select the first code No.
button and select the second code No.
button one time and "define" the currently set contents.
button to return to the normal mode.
: http://splitoff.ru/tehn-doc.html
Test Operation
