Introduction
1.3

Combination

The combination with indoor units is as follows:
The possible combination of the outdoor unit with indoor units is in function of the total capacity index of
these indoor units and must be within the range as specified below:
Outdoor Unit
RSXY16 < RXY8 + RXE8 >......................................................................................
RSXY18 < RXY10 + RXE8 >....................................................................................
RSXY20 < RXY10 + RXE10 >..................................................................................
RSXY24 < RXY16 + RXE8 >....................................................................................
RSXY26 < RXY16 + RXE10 >..................................................................................
RSXY28 < RXY20 + RXE8 >....................................................................................
RSXY30 < RXY20 + RXE10 >..................................................................................
Up to 20 indoor units can be connected to 1 outdoor unit RSXY16,18 and 20.
Up to 32 indoor units can be connected to 1 outdoor unit RSXY24,26,28 and 30.
Refer to the catalogue and/or engineering data book for model numbers of indoor units which can be
connected.
130
200 - 520
225 - 585
250 - 650
300 - 780
325 - 845
350 - 910
375 - 975
