Between outdoor unit and first branch kit (C)
Applicable Model
RXY16KA
RXY18~20KA
RXY24KA
RXY26~30KA
Between branches kit (D)
Total Capacity Index of Indoor
Unit after Branch
Below 100
100 to below 160
160 to below 330
330 to below 480
480 to below 640
640 and over
General Information
×
Pipe Size (out. dia. min. wall thickness)
Liquid Pipe Gas Pipe (main)
φ15.9 × φ34.9 ×
t1.0 t1.3
φ19.1 × φ34.9 ×
t1.0 t1.3
φ19.1 × φ41.3 ×
t1.0 t1.7
φ22.2 × φ41.3 ×
t1.2 t1.7
×
Pipe Size (out. dia. min. wall thickness)
Liquid Pipe Gas Pipe
× ×
φ9.5 φ15.9
t0.8 t1.0
× ×
φ9.5 φ19.1
t0.8 t1.0
× ×
φ12.7 φ25.4
t0.8 t1.2
φ15.9 × φ34.9 ×
t1.0 t1.3
φ19.1 × φ34.9 ×
t1.0 t1.3
φ19.1 × φ41.3 ×
t1.0 t1.7
