Technical data and limit values

7.3 Version

The specific version name can be found on the type label at the slot bracket of your board.

7.4 Options

Please specify the number of channels when ordering one of the following options for the APCI-3003
board!
Option
DF
PC-Diff

7.5 Limit values

Height:
Operating temperature:
Storage temperature:
Relative air humidity
at indoor installation:
Minimum PC requirements:
System bus:
Bus speed:
Required space:
Operating system:
Energy demand:
Operating voltage from the PC:
Current consumption (typ., without load)
www.addi-data.com

Table 7-1: Options

Precision filter for 1 differential channel
Current input 0-20 mA or 4-20 mA for 1 differential channel

Table 7-2: PC-Diff option: Resolution

Measurement range
0-20 mA
4-20 mA
Features
Resolution (16-bit)
0 to 65535
13107 to 65535
2000 m over NN
0-60 °C (with forced ventilation)
-25 °C to +70 °C
50 % at +40 °C
80 % at +31 °C
PCI 32-bit
≤ 33 MHz
analog inputs and digital I/O: 1 PCI slot
Windows 8, Windows 7, Windows XP, Linux
5 V ± 5 %
1.55 A ± 10 %
34
