CONTROL BOARD OPERATION

Menu Map

->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
www.event-lighting.com.au
- Select DMX address for 6 ch mode
- Select DMX address for 10 ch mode
or Set dimming speed (SL: slow / FA: fast)
When lost DMX signal,
or
ho: keep the last DMX signal state
OF: blackout
or Switch on/off wireless DMX control
or Switch on/off IR remote control
- Set red colour intensity
- Set green colour intensity
- Set blue colour intensity
- Set white colour intensity
- Set amber colour intensity
- Set UV colour intensity
- Display IR control brightness level
- Set strobe speed
Select 15 static colour modes, see chart: Static
-
colour mode
- Select 16 speed of auto colour switch mode
- Select 16 speed of auto colour fading mode
- Select 16 speed of auto colour pulse out mode
Select sound active mode with different sound
-
sensitive level
