Event Lighting PRO PAR PAR6X12OB User Manual page 7

Protocols
TABLE1
Colour Protocol
Red ELDMX Transmit and receive
Green W-DMX Receive
Blue W-DMX G3 Transmit
Yellow W-DMX G4 Transmit
Purple GZ Receive* (*Receiver Only)
Using W-DMX mode
Transmitters
Pressing the button momentarily will connect to all unconnected receivers in the coverage area.
Pressing the button for more than 3s will disconnect all receivers in the coverage area.
Receivers
Pressing the button for more than 3s will disconnect the device with a transmitter.
NOTE:
The colour of the light will indicate the group as shown in Table2.
The receiver will not connect with a new transmitter unless it is disconnected first.
W-DMX Status Indicators
Protocol Action
W-DMX Receive White
Red
Red Fast Flash
Green Fast Flash
Green Slow Flash
Green
W-DMX Transmit Red
Blue Fast Flash
Blue Slow Flash
Blue
Using EL wireless DMX mode
Changing Channel Group
Pressing the Button will show you the current channel group being used and pressing it again will cycle through the
groups. The colour of the light will indicate the group as shown in Table3.
Status Indicators
TABLE3
Protocol Action
ELDMX / GZ Solid Colour (Red, Green, Blue,
Yellow, Cyan, Magenta, White*)
Flashing Red
Flashing Green
www.event-lighting.com.au
TABLE2
Description
No connection
Deleting Connection
Connection Lost
Connecting to Transmitter
Connected but no DMX signal
Connected with DMX signal
Deleting All Receivers
Connecting with the receivers
No DMX input
Transmitting DMX
Description
1 of the 7* colour groups
(*7th white only in GZ mode, 6 in WIDMX modes)
Transmitting DMX
Receiving DMX
