Control Board Operation

->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
->
www.event-lighting.com.au
-
-
or
or
or
or
-
-
-
-
-
-
-
-
-
-
-
-
-
or
3
Select DMX address for 6 ch mode
Select DMX address for 10 ch mode
Set dimming speed (SL: slow / FA: fast)
When lost DMX signal,
ho: keep the last DMX signal state
OF: blackout
Switch on/off wireless DMX control
Switch on/off IR remote control
Set red colour intensity
Set green colour intensity
Set blue colour intensity
Set white colour intensity
Set amber colour intensity
Set UV colour intensity
Display IR control brightness level
Set strobe speed
Select 15 static colour modes, see chart:
Static colour mode
Select 16 speed of auto colour switch mode
Select 16 speed of auto colour fading mode
Select 16 speed of auto colour pulse out
mode
Select sound active mode with different
sound sensitive level
Display current temperature
Display version number
Reset
