Setting the signal level for speech detection is sometimes found difficult.
However, setting it correctly only has to be done once, will prevent future
problems, and boosts the quality of recording.
We advise you therefore to adjust your Call Recorder to your handset in the
way described below. Before you start adjusting, all cables should have been
properly connected.
Proceed as follows:
1. Enter the menu via the menu key
2. Select "lifting the handset" with the 'CHANGE' softkey
3. Press the 'MORE' softkey. You will now see the "start" menu
4. With the 'CHANGE' softkey select "speech-detection"
5. Press the 'MORE' softkey. The display will now say "signal setting"
6. Press the 'CHANGE' softkey.
You have now reached the graphical screen for adjusting the signal level and
the start and stop levels.
A4•••:•|••••••••••••••••
<< >>
In order to get the correct settings dial a telephone number and with the help
of the person on the other end set the Call Recorder .
When connected proceed as follows:
1. Check if the signal comes to about halfway along the scale when
speaking.
2. If the signal remains continuously in the lower half, select * to
increase the amplification (A 4 changes to A5, A6, A7)
3. If the signal is well beyond the middle during a normal conversation,
continue pressing * until you see A0, A1, A2 appear.
4. Now press the # key. You will see the B channel (display says B4)
