Installing the Drawer

The drawer mounts to the forward, left,
underside of the table when the stand is upright.
To install the drawer, locate the rough position
8) and put the drawer rails and the
(Figure
drawer in position. The drawer should pull open
from the front of the table
pushed in, it will hit a stop. Secure the rails to the
underside of the table with the included screws
(K) on page 4 (Figure
Tip: Do not over tighten the screws or they will
prevent the drawer from sliding freely.
5 |
9) and when
(Figure
10).
FRONT
Drawer Location
FRONT
8
9
10
