MACHINE SPECIFICATIONS

APPLICATION
SEWING SPEED
MAX STITCH LENGTH
PRESSER FOOT LIFT
NEEDLE
SHUTTLE
LUBRICATION
WEIGHT
BED SIZE
UNDERARM SPACE
BUILT-IN KNEE LIFT
The sewing machine casting does not have an internal motor. It is powered by Sailrite's exclusive
Workhorse Servo motor using Sailrite's patented Posi-Pin system (Pat. #7438009) and Stitch PRO
Balance Wheel.
75 |
Light, Medium & Heavy-Duty
123 spm to 1108 spm
0-8mm (Straight Stitch Only)
Hand 6.5mm (1/4"), Knee Lift 14mm (9/16")
System 135 x 17 & 135 x 16 Sizes #10 - #24
Full Rotary, Gear Driven, Large Style M Bobbin
Auto Lubrication
79 lbs.
18.75" X 7"
10.25" X 5"
Yes
