4. Rotate the balance wheel until the needle is
at the bottom of its stroke.
5. Continue to rotate the balance wheel until the
needle comes up 2.5mm from its lowest setting
88).
(Figure
To do this, rotate the balance wheel so that the
needle is at it's lowest position. Make a mark on
a paper 2.5mm from the edge. Hold the paper
up to where the needle bar meets the machine
casting and make a mark on the bar at the
2.5mm location (Figure
Rotate the balance wheel until the mark lines up
with the machine casting
Sailrite Fabricator Guidebook
86).
(Figure 87).
86
87
MARK
88
