Adjusting Needle Position &
Clearance Between Presser Feet
To prevent the inner presser foot from striking
the outer presser foot at the end of feeding, the
needle should be positioned in the center of the
feed dog hole. Rotate the balance wheel so the
inner presser foot is at its furthest back position,
toward the outer presser foot
two presser feet should not touch. Now rotate
the balance wheel so the feed dog is as far
forward as possible (away from outer presser
foot). The needle should be centered in the feed
dog hole.
If it needs adjustment, loosen the screw for the
motion shaft crank (Figure
the needle moves near the back of the feed dog
hole. Grabbing the needle bar and inner presser
foot, hold them in a position so that needle is
in the center of the feed dog hole
Tighten the screw (Figure
properly. Make a full rotation of the balance
wheel and confirm the inner and outer presser
feet still don't touch (Figure
If adjustment is made, please refer to the
"Note About Adjustments" on page 44.
45 |
77). The
(Figure
78) and notice that
(Figure 79).
78) when positioned
77).
77
78
79
