3. Place the top of the table on the floor with
the laminate surface down. Place on a soft
surface to avoid scratching the tabletop.
Squarely line up the table legs as shown
5). Be sure that the legs are facing
(Figure
the correct direction. Reference the cutout
shape in the tabletop to aid in placement.
4. Use a pencil to mark screw locations for
attaching the K-leg frame to the tabletop
6). Use a 5/32" drill bit and drill
(Figure
about 1/2" into the tabletop. Do not drill
completely through.
5. Bolt the frame to the bottom of the tabletop
using the enclosed hex head lag screws (J),
locking washer (L) and washer (M) to lock at
each position (Figure
K
Sailrite Fabricator Guidebook
7).
J
L
M
1.5"
0.5"
5
6
7
| 4
