Sew like a pro with Sailrite ® Table of Contents Leatherwork Linkage Bar Installation 11 For in-depth information on setup and Legs & Tabletop Components ������������������� 1 Install Oil Tray & Hinges 12 assembly of your Leatherwork Sewing Tabletop & Legs 1 Install Sewing Machine &... -
Page 3: Leatherwork Legs & Tabletop Components
Leatherwork Legs & Tabletop Components Tabletop & Legs Hardware Tabletop & Legs Sailritecom Leatherwork Assembly Instructions ®... -
Page 4: Leatherwork Sewing Machine Components
Leatherwork Sewing Machine Components Servo Motor Box Accessories Head Box Sailritecom Leatherwork Assembly Instructions ®... -
Page 5: Assembling The Leatherwork
Once the table is upright this makes it easier to adjust one or two feet to level the table Once adjusted, use the nut to lock the position permanently Sailritecom Leatherwork Assembly Instructions ®... -
Page 6: Assemble & Attach Treadle
(J) Tighten down L-Bracket in place Important: Check to make sure the treadle moves freely after the bolts (F) are tightened If not, loosen bolt and reposition one of the pivots TABS Sailritecom Leatherwork Assembly Instructions ®... -
Page 7: Preparing Workhorse ® Motor
Servo Motor The side of the Workhorse Motor (K) should be perfectly vertical with the ground Use a Triangle or Square (L) to set the angle and tighten the pivot screw (J) 3/8 inch (0�95cm) Sailritecom Leatherwork Assembly Instructions | 10 ®... -
Page 8: Linkage Bar Installation 11
Increasing or decreasing the overlap of the linkage bar changes the angle of the treadle pedal (E) Note: You want at least a 1/4-inch clearance between the bottom of the treadle pedal and the floor (F) 11 | Sailritecom Leatherwork Assembly Instructions | 12 ®... -
Page 9: Install Sewing Machine & Cover Bracket
Posi-Pin Nut (M) to store Note: Always rotate the balance wheel by grabbing the top of the wheel and rotating down toward you (K) 13 | Sailritecom Leatherwork Assembly Instructions | 14 ®... -
Page 10: Installing Timing Belts
There should be equal tension between the two belts If one is looser, use the box end wrench (C) to loosen and tighten the idler pulley accordingly (26) 15 | Sailritecom Leatherwork Assembly Instructions | 16 ®... -
Page 11: Changing Motor Rotation
Use the included adhesive pieces and wire ties ( ) to secure the light cord in your desired locations Make sure to keep the cord out of the way of any moving machine parts 17 | Sailritecom Leatherwork Assembly Instructions | 18 ®... - Page 12 Never rotate in the other direction Use the foot lift (C) to lift the feet Remove the fabric sample and how to set your stitch length, and general maintenance and troubleshooting cut the thread coming from below the machine Continue to the LEATHERWORK Guidebook 19 | Sailritecom Leatherwork Assembly Instructions | 20 ®...
- Page 13 One of our support staff members will review your case and contact you Sailrite.com Equipping you to sew Serial #: ������������������������������������������� Date of Purchase: ������������������������������������ 122926*1 122926*1 Assembly Instructions for Sailrite Leatherwork ® ® Leatherwork Patented Technology ® Qty: 1...
