Danfoss ADAP-KOOL AK-HP 780 Design Manual page 19

Point
DO
AK-HP 780
Point 1
Type DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8
Signal Active at
Comp. 1
Comp. 2 On
/
Pump Off
Alarm
Solenoid
valve
Heat pump controller
2 3 4 5 6 7 8
Signal Module
RS8GF202 © Danfoss 2015-08
Point Terminal
1 (DO 1) 25 - 27
2 (DO 2) 28 - 30
3 (DO 3) 31 - 33
4 (DO 4) 34 -36
5 (DO 5) 37 - 39
6 (DO 6) 40 - 41 - 42
7 (DO 7) 43 - 44 - 45
8 (DO 8) 46 - 47 - 48
Active at
19
