Tektronix IsoVu TIVM Series User Manual page 50

Reference information
Table 9: Electrical specifications (cont.)
Characteristic
Common mode rejection ratio (Typical)
Sensor tip cable/adapter
IVTIP1X, 1X Sensor tip
cable
IVTIP5X, 5X Sensor tip
cable
IVTIP10X, 10X Sensor
tip cable
IVTIP25X, 25X Sensor
tip cable
IVTIP50X, 50X Sensor
tip cable
MMCX-to 0.1 in
(2.54 mm) square pin
adapter with sensor tip
cable.
MMCX-to 0.062 in
(1.57 mm) square pin
adapter with sensor tip
cable.
Common mode voltage
range
Common mode resistance
(Typical)
Common mode
3
capacitance
(Typical)
Overload indicator range
(Typical)
1
The difference between the measured DC gain and the nominal DC gain, divided by the nominal DC gain and expressed as a percent.
2 The input referred offset error voltage when the input is shorted and the probe input offset is set to 0 volts
3 The capacitance between the sensor head and a reference plane. The sensor head is placed six inches (15.25 cm) above the reference plane.
32
Description
DC 100 MHz
> 120 dB 120 dB
> 120 dB 120 dB
> 120 dB 120 dB
> 120 dB 110 dB
> 120 dB 100 dB
> 120 dB 70 dB
> 120 dB 70 dB
2 kVpk (2 kV CAT I, 1000 V CAT II)
N.A. due to Galvanically isolation (fiber optic connection)
~2 pF
Sensor tip cable/adapter
Sensor head input SMA
IVTIP1X, 1X Sensor tip cable
IVTIP5X, 5X Sensor tip cable
IVTIP10X, 10X Sensor tip cable
IVTIP25X, 25X Sensor tip cable
IVTIP50X, 50X Sensor tip cable
200 MHz 500 MHz
110 dB 100 dB
110 dB 100 dB
110 dB 100 dB
100 dB 100 dB
90 dB 90 dB
60 dB 40 dB
60 dB 40 dB
Overload indicator On
V < -3 V or V > +3 V
in in
V < -3 V or V > +3 V
in in
V < -12 V or V > +12 V
in in
V < -16 V or V > +16 V
in in
V < -25 V or V > +25 V
in in
V < -35 V or V > +35 V
in in
TIVM Series Measurement System User Manual
1 GHz
90 dB
90 dB
90 dB
90 dB
80 dB
30 dB
30 dB
