Environmental
requirements
TIVM Series Measurement System User Manual
The following tables describe specifications and maximum operating
environmental ratings for the measurement system when connected to a DUT
and a Tektronix oscilloscope.
Table 3: Input specifications
Feature
Common mode
Differential mode

Table 4: Environmental considerations

Feature
Temperature
Controller
Operating
Non-operating
Sensor head
Operating
Non-operating
Sensor tip cables/adapters
Operating and
non-operating
Humidity
Controller
Operating
Non operating
Sensor head
Operating
Non operating
Description
1000 V , CAT II
rms
2000 V peak, CAT I (expected transient voltage 2500 V peak)
Sensor tip cable dependent (See the Sensor tip cable voltage
rating below.)
Description
0 °C to 40 °C (32 °F to 104 °F)
-40 °C to 70 °C (-40 °F to 158 °F)
0 °C to 70 °C (32 °F to 158 °F)
-40 °C to 70 °C (-40 °F to 158 °F)
-40 °C to 85 °C (-40 °F to 185 °F)
5% to 85% RH (Relative Humidity), at up to 40 °C (104 °F),
non-condensing
5% to 85% RH (Relative Humidity), at up to 40 °C (104 °F)
5% to 45 % RH above 40 °C (104 °F) up to 70 °C (158 °F),
non-condensing
5% to 80% RH (Relative Humidity), at up to 40 °C (104 °F)
5% to 45 % RH above 40 °C (104 °F) up to 70 °C (158 °F),
non-condensing
5% to 85% RH (Relative Humidity), at up to 40 °C (104 °F)
5% to 45 % RH above 40 °C (104 °F) up to 70 °C (158 °F),
non-condensing
Operating information
3
