Sensor head
Sensor tip cables

Models

Supported oscilloscopes

TIVM Series Measurement System User Manual
The sensor head provides an interface between the device-under-test (DUT) and
the controller. It contains an electro-optic converter that converts the electrical
signal from the sensor tip cables to an optical signal sent to the controller.
Different sensor tip cables are available to connect the measurement system to
the DUT. The sensor tip cable consists of an SMA connector that connects to the
sensor head; two screws to secure the sensor tip cable to the sensor head; the other
end of the sensor tip cable connects to the DUT through an MMCX connector
and optional adapters.
The TIVM Series IsoVu Measurement System includes the following models:
TIVM1. Tektronix IsoVu 1 GHz Medium Voltage with 3 m cable
TIVM1L. Tektronix IsoVu 1 GHz Medium Voltage with 10 m cable
TIVM05. Tektronix IsoVu 500 MHz Medium Voltage with 3 m cable
TIVM05L. Tektronix IsoVu 500 MHz Medium Voltage with 10 m cable
TIVM02. Tektronix IsoVu 200 MHz Medium Voltage with 3 m cable
TIVM02L. Tektronix IsoVu 200 MHz Medium Voltage with 10 m cable
The measurement system can be used with the following Tektronix oscilloscopes.
For oscilloscopes not included in this list, contact your local Tektronix
representative.
MDO3000 series
MSO/DPO4000B series
MDO4000B/C series
MSO/DPO5000B series
DPO7000C series
In addition to the above oscilloscopes, the measurement system can also be used
with the following oscilloscopes with a TCA-VPI50 adapter.
MSO/DPO70000C series
MSO/DPO70000DX series
DPO70000SX series
