Tektronix IsoVu TIVM Series User Manual page 48

Reference information
Table 9: Electrical specifications (cont.)
Characteristic
Input
resistance/capacitance
(attached to sensor head,
50 Ω termination), (Typical)
Maximum non-destructive
differential input voltage
range, (Typical)
CAUTION.
To avoid
damaging the measurement
system, be aware of the
input voltage limits; this
specification applies to
both the 1X Range and 2X
Range.
Linear differential input
voltage range, (Typical)
Output clamping range
(Input referred)
(Typical)
Output clamping overdrive
recovery (Typical)
30
Description
Sensor tip cable/adapter
Sensor head input SMA
IVTIP1X, 1X Sensor tip cable
IVTIP5X, 5X Sensor tip cable
IVTIP10X, 10X Sensor tip cable
IVTIP25X, 25X Sensor tip cable
IVTIP50X, 50X Sensor tip cable
Sensor tip cable/adapter
Sensor head input SMA
IVTIP1X, 1X Sensor tip cable
IVTIP5X, 5X Sensor tip cable
IVTIP10X, 10X Sensor tip cable
IVTIP25X, 25X Sensor tip cable
IVTIP50X, 50X Sensor tip cable
Sensor tip cable/adapter
Sensor head input SMA
IVTIP1X, 1X Sensor tip cable
IVTIP5X, 5X Sensor tip cable
IVTIP10X, 10X Sensor tip cable
IVTIP25X, 25X Sensor tip cable
IVTIP50X, 50X Sensor tip cable
Sensor tip cable/adapter
Sensor head input SMA
IVTIP1X, 1X Sensor tip cable
IVTIP5X, 5X Sensor tip cable
IVTIP10X, 10X Sensor tip cable
IVTIP25X, 25X Sensor tip cable
IVTIP50X, 50X Sensor tip cable
< 20 ns
Resistance Capacitance
50 Ω ± 2% NA
50 Ω NA
< 1pF
250 Ω
500 Ω < 1pF
1.25 kΩ < 1pF
2.5 kΩ < 1pF
V V peak
rms
3 V 4.3 Vpk
3 V 4.3 Vpk
12 V 21.5 Vpk
16 V 43 Vpk
25 V 107.5 Vpk
35 V 200 Vpk
Clamping Off, Clamping Off,
1X Range 2X Range
±V peak ±V peak
(DC + peak AC) (DC + peak AC)
±0.5 V ±1 V
±0.5 V ±1 V
±2.5 V ±5 V
±5 V ±10 V
±12.5 V ±25 V
±25 V ±50 V
Clamping on, Clamping on,
1X Range 2X Range
± 100 mV ± 200 mV
± 100 mV ± 200 mV
± 500 mV ± 1 V
± 1 V ± 2 V
± 2.5 V ± 5 V
± 5V ± 10 V
TIVM Series Measurement System User Manual
