Reference information

Specifications
Table 8: Warranted specifications
Characteristic
Propagation delay (Warranted)
Table 9: Electrical specifications
Characteristic
Controller output
termination
Controller output coupling
Range attenuation
TIVM Series Measurement System User Manual
The following tables list the specifications for the measurement system. The
specifications are guaranteed unless otherwise indicated.
The performance limits in this specification are valid with these conditions:
The instrument must be in an environment with temperature, altitude, and
humidity within the operating limits described in these specifications.
The instrument must have had a warm-up period of at least 20 minutes.
The measurement system is powered from a TekVPI compatible oscilloscope.
Warranted specifications describe guaranteed performance with tolerance limits or
certain type-tested requirements.
The performance verification procedures for the Propagation delay are listed later
in this document. (See page 47, Propagation delay.)
Description
3 m fiber length: 35 ns ±5 ns (actual propagation delay is measured and stored within each unit)
10 m fiber length: 68 ns ±7 ns (actual propagation delay is measured and stored within each
unit)
Description
Terminate the controller output into 50 Ω
DC coupled
Sensor tip cable/adapter
Sensor head input SMA
IVTIP1X, 1X Sensor tip cable
IVTIP5X, 5X Sensor tip cable
IVTIP10X, 10X Sensor tip cable
IVTIP25X, 25X Sensor tip cable
IVTIP50X, 50X Sensor tip cable
1X range 2X range
1X (÷1) 2X (÷2)
1X (÷1) 2X (÷2)
5X (÷5) 10X (÷10)
10X (÷10) 20X (÷20)
25X (÷25) 50X (÷50)
50X (÷50) 100X (÷100)
29
