• You must prevent external logic from interfering with device programming. Make sure that recovered sysCONFIG
pins are not asserted when the MachXO2 is in Feature Row HW Default Mode state. One example is driving
PROGRAMN with an active low signal after the MachXO2 is in Feature Row HW Default Mode state. Failure to
reprogram the Feature Row with PROGRAMN disabled prevents the FPGA from configuring and entering user
mode.
• Use care when using JTAGENB to selectively enable and disable the JTAG port. Any external logic connected to
the JTAG I/O must not contend with the JTAG programming port.
Table 7 lists the default state of the shared sysCONFIG pins. As you can see, a Default Mode Feature Row device
has the JTAG, SPI Slave and I
2
SSPI, and I C sysCONFIG pins become general purpose I/O. This means you lose the ability to program the
MachXO2 using SSPI, or I
FIG pins in user mode, be sure to ENABLE them using the Diamond Spreadsheet View editor.
Unless specified otherwise, the sysCONFIG pins are powered by the VCCIO0 voltage. It is crucial you take this into
consideration when provisioning other logic attached to Bank 0.
The function of each sysCONFIG pin is described in detail.
Table 7. Default State of the sysCONFIG Pins
Associated
Pin Name sysCONFIG Port
PROGRAMN
INITN
DONE
MCLK/CCLK SSPI/MSPI
SN SSPI/MSPI
SI/SISPI SSPI/MSPI
SO/SPISO SSPI/MSPI
CSSPIN
SCL
SDA
1. All pins will be in Configuration Mode until the device is configured and enters User Mode.
2. Disabled sysConfig Pins will assume h/w default behavior in User Mode, that is, high-impedance with a weak pull down.
Table 8. Default State in Diamond for Each Port
SDM_PORT
SLAVE_SPI_PORT
I2C_PORT
MASTER_SPI_PORT
JTAG_PORT
1. This Default setting can be modified in the Diamond Spreadsheet View, Global Preferences tab.
Self Download Port Pins
PROGRAMN: The PROGRAMN is an input used to configure the FPGA. The PROGRAMN pin, when enabled, is
sensitive to a high-to-low transition, and has an internal weak pull-up. When PROGRAMN is asserted low, the
FPGA exits user mode and starts a device configuration sequence at the Initialization phase, as described earlier.
Holding the PROGRAMN pin low prevents the MachXO2 from leaving the Initialization phase. The PROGRAMN
MachXO2 Programming and Configuration Usage Guide
2
C ports enabled. Upon entry to User Mode the MachXO2, the default state of the
2
C when using the default sysCONFIG port settings. To retain the SSPI, or I
1
Pin Function in
Feature Row Erased Mode
(Configuration Mode)
SDM
SDM
SDM
MSPI
2
I C
2
I C
sysConfig Port
(Configuration Mode)
PROGRAMN Input with weak pull up
I/O I/O with weak pull up
I/O I/O with weak pull up
SSPI Input with weak pull up
SSPI Input with weak pull up
SSPI
SSPI
I/O I/O with weak pull up
2
I C
2
I C
12
Pin Direction Default Function
User-defined I/O
User-defined I/O
User-defined I/O
User-defined I/O
User-defined I/O
Input User-defined I/O
Output User-defined I/O
User-defined I/O
Bi-Directional User-defined I/O
Bi-Directional User-defined I/O
1
Diamond Default
Disable
Disable
Disable
Disable
Enable
2
C sysCON-
2
in User Mode
