Message
F06
Pliers control not
connected. Please connect
plug.
F07
Work pressure too low.
F09
Timeout occurred on CAN
bus
F33
Please check cap and
change cap, if necessary.
F34
Central connection
overheated.
F35
No tool recognised. Please
insert a tool.
F36
Wrong tool for selected
program – Please connect
tool as per indication.
F37
No electrode identification
available. – Select type of
electrode.
F38
Tool is overheated. –
Welder remains locked until
cooled off.
What's the problem
The plug for measuring the
impedance at the front sheet has not
been connected.
The impedance measuring cable is
defective.
The IO board is defective.
Compressed air has not been
connected. Pressure too low.
The CAN bus between the control
unit and IO board detected too many
errors.
Message appears at start-up and
after 50 welding spots.
The central connection is overheated. Interrupt current welding
Central connection is not tight.
The plug of the temperature sensor
has gone loose.
A tool has not been connected.
Otherwise, the tool must be
defective.
The tool connected is not right for the
welding program that has been
selected.
(Message can occur only with OEM
and own programs.)
You're using uncoded electrodes.
Electrode ID of the tool is defective.
The impedance measuring cable is
defective.
The tool is overheated.
Temperature sensor of the tool is
defective.
The throughput of water inside the
tool is too low.
Resistance welder MULTISPOT MI-100control
What should be done?
Replace plug.
Check the cable.
If the cable must be
replaced, call service.
Call service.
Check compressed-air
connection and –pressure
"5.6".
Check the cables installed.
Check the caps. Mill them /
replace them, if necessary.
"6.1.2".
job. Let the pump run.
Re-tighten.
Re-tighten.
Connect a tool.
Replace the tool.
Check selected program.
Connect the required tool.
Check the programming.
Set the type of electrode
manually
"6.4.3".
Have the throughput of the
cooling water pump
checked.
Have the temperature
sensor of the tool checked.
Have the throughput of the
cooling water pump
checked.
Troubleshooting
Who should
do it?
Operator
Operator
Service
Operator
Operator
Operator
Operator
Operator
Service
