Specifications; Dimensions And Weights; Power Requirements - Elektron MULTISPOT MI-100control Operating Manual

9

Specifications

9.1

Dimensions and weights

Item
Height
Width
Depth
Weight (w/o accessories)
9.2

Power requirements

Power supply
Item
Mains voltage
Admissible voltage range
Power cord
Mains fuse, min.
Installed power
Rated output at 50% duty cycle
No load voltage, max.
weld current, regulated, max.
Enclosure
Compressed-air supply
Item
Operating pressure, min. – max.
Quality
Cooling water pump
Item
Operaiting air pressure
Flow rate
Resistance welder MULTISPOT MI-100control
Value Unit
1100 /43 mm / in
690 /27 mm / in
600 /23.6 mm / in
100 / 220 kg / lb
Value Value
480 / 3 ~ 400 / 3 ~
50 / 60 50 / 60
440 – 500 380 – 415
6 6
AWG 10 AWG 10
32 32
42 42
60 60
23 23
12000 12000
IP21
Value Unit
6 – 10 bar
87 – 145 Psi
clean, dry, free of oil
Value Unit
6 / 87 bar / Psi
2.5 /0.66 l/min / gal
Specifications
Value Unit
230 / 3 ~ V / Ph
50 / 60 Hz
208 – 240 V (AC)
2
16 mm / 10 m
AWG 6 33 ft
63 A slow-blow
42 kVA
60 kVA
23 V (DC)
12000 A (DC)
85
