6.4.2.2

Setting welder in mode "Keyboard operation"

Keyboard
Program selectio
Free mode
Fig. 53: Selecting the control mode
Welding job
(*) optionally ON or OFF
(!) "3 sheets" OFF
1. Use the control knob to select mode
2. Use a calliper gauge to measure the sheet gauges for the
3. Determine the pertinent gauges for the job using the
3
4. Using the following table, determine the set value
Ratio of sheets Sheet gauges up to
0,8 + 0,8 + 0,8
1,0 + 1,0 + 1,0
d1 = d2 = d3
1,5 + 1,5 + 1,5
2,0 + 2,0 + 2,0
2,0 + 0,8 + 0,8
0,8 + 1,0 +1,0
d2 ≈ d3 0,8 + 1,5 + 1,5
0,8 + 2,0 + 2,0
0,8 + 3,0 + 3,0
d1 + d2 + d3 ≤ 3
d1 < d2 < d3 Select next higher
Resistance welder MULTISPOT MI-100control
"Program selection". Confirm.
welding job at hand.
following table.
required. Use the touch keys (Fig. 53) to enter the set
value.
Set value
about
set value.
Operation
Selection
47
