Whirlpool AER5522VAS0 Manual

Freestanding gas and electric range controls troubleshooting guide
Hide thumbs

Advertisement

Quick Links

KR38
Technical Education
Troubleshooting Gas and
Electric Freestanding Range
Electronic Controls
KitchenAid
Amana
Maytag
Whirlpool
Job Aid W10378809
Prepared by: WHIRLPOOL CONSUMER CARE

Advertisement

loading

  Related Manuals for Whirlpool AER5522VAS0

  Summary of Contents for Whirlpool AER5522VAS0

  • Page 1 KR38 Technical Education Troubleshooting Gas and Electric Freestanding Range Electronic Controls KitchenAid Amana Maytag Whirlpool Job Aid W10378809 Prepared by: WHIRLPOOL CONSUMER CARE...
  • Page 2 WHIRLPOOL CORPORATION assumes no responsibility for any repairs made on our products by anyone other than authorized In-Home Service Professionals. ®Registered trademark of Whirlpool, U.S.A., KitchenAid, U.S.A., Jenn-Air, U.S.A., or Maytag Corporation or its related companies. ®MAGIC CHEF is a registered trademark of CNA International, used under license.
  • Page 3 Table of Contents Model Control, Range Description Page Tech Sheet F Codes Model Control, Range Description Page Tech Sheet F Codes AER5522VAS0 LCC95, Self Clean, Electric 1-11 W10198623 1-26 AER5522VAW0 LCC95, Self Clean, Electric 1-11 W10198623 1-26 AER5522VCS0 LCC95, Self Clean, Electric 1-11 W10198623 1-26 AER5522VCW0 LCC95, Self Clean, Electric...
  • Page 4 Table of Contents Model Control, Range Description Page Tech Sheet F Codes GFE461LVB0 MRC, True Convection, Electric, W10198585 2-10 GFE461LVQ0 MRC, True Convection, Electric, W10198585 2-10 GFE461LVS0 MRC, True Convection, Electric, W10198585 2-10 GFE461LVT0 MRC, True Convection, Electric, W10198585 2-10 GFE471LVB0 MRC, True Convection, Warming Drawer, Electric, W10198586 2-10 GFE471LVQ0 MRC, True Convection, Warming Drawer, Electric,...
  • Page 5 Table of Contents Model Control, Range Description Page Tech Sheet F Codes MER7662WB0 LCC95, Self Clean, Electric 1-11 W10237513 1-26 MER7662WB1 LCC95, Self Clean, Electric 1-11 W10237513 1-26 MER7662WQ1 LCC95, Self Clean, Electric 1-11 W10237513 1-26 MER7662WS0 LCC95, Self Clean, Electric 1-11 W10237513 1-26 MER7662WS1 LCC95, Self Clean, Electric 1-11 W10237513 1-26...
  • Page 6 Table of Contents Model Control, Range Description Page Tech Sheet F Codes MGR7662WS1 LCC190, Self Clean, Gas 1-15 W10198615 1-26 MGR7662WW0 LCC190, Self Clean, Gas 1-15 W10198615 1-26 MGR7662WW1 LCC190, Self Clean, Gas 1-15 W10198615 1-26 MGR7665WB0 LCC190, Self Clean, Gas 1-15 W10198615 1-26 MGR7665WB1 LCC190, Self Clean, Gas 1-15 W10198615 1-26...
  • Page 7 Table of Contents Model Control, Range Description Page Tech Sheet F Codes WFE301LVS0 LCC90, Standard Clean, Electric W10251245 1-26 WFE321LWB0 LCC90, Standard Clean, Steam,Electric W10267424 1-26 WFE321LWQ0 LCC90, Standard Clean, Steam,Electric W10267424 1-26 WFE321LWS0 LCC90, Standard Clean, Steam,Electric W10267424 1-26 WFE324LWB0 LCC90, Standard Clean, Steam,Electric W10267424 1-26 WFE324LWQ0 LCC90, Standard Clean, Steam,Electric W10267424 1-26...
  • Page 8 Table of Contents Model Control, Range Description Page Tech Sheet F Codes WFG371LVS1 LCC190, Self Clean, GAS 1-14 W10198618 1-26 WFG374LVB0 LCC190, Self Clean, GAS 1-14 W10198618 1-26 WFG374LVB1 LCC190, Self Clean, GAS 1-14 W10198618 1-26 WFG374LVD0 LCC190, Self Clean, GAS 1-14 W10198618 1-26 WFG374LVD1 LCC190, Self Clean, GAS 1-14 W10198618 1-26...
  • Page 9 Table of Contents Model Control, Range Description Page Tech Sheet F Codes YMERH770WW1 MRC, Fan Convection, Electric, W10239462 2-10 YMET8665XB00 MRC II, Double Oven, Electric W10311745 3-16 YMET8665XS00 MRC II, Double Oven, Electric W10311745 3-16 YMET8665XW00 MRC II, Double Oven, Electric W10311745 3-16 YMET8885XB00 MRC II, Dble Oven, True Convect Lower, Warm Zone, Electric W10311747 3-16 YMET8885XS00...
  • Page 10 NOTES...
  • Page 11 LCC Standard Clean, Electric LCC90 Control, Standard Clean, Electric Models: WFE114LWS0 WFE301LVB0 WFE301LVQ0 WFE301LVS0 YRF115LXVB0 YRF115LXVQ0 YRF115LXVS0 YWFE301LVB0 YWFE301LVQ0 YWFE301LVS0 IVE32300 IVE82300 LCC190 Control, Standard Clean, Steam Clean, Electric Models: WFE321LWB0 WFE321LWQ0 WFE321LWS0 WFE324LWB0 WFE324LWQ0 WFE324LWS0 Reviewed by Genview Automated Process | Released LCC90 Control, Standard Clean, Electric Models: AER5821VAS0...
  • Page 12 LCC Standard Clean, Electric (continued) LCC180 Control, Standard Clean, Electric Models: AER5822VAB0 AER5822VAD0 AER5822VAS0 AER5822VAW0 AER5822VCB0 AER5822VCS0 AER5822VCW0 AER5823XAB0 AER5823XAS0 AER5823XAW0 Temperature Adjustment 1. Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed. bra L. | Released Adjusts temperature in 10⁰...
  • Page 13 FOR SERVICE TECHNICIAN’S USE ONLY Wiring Diagram Wiring Information TS W10267424 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Oven Control LCC190 Door Position Switch CON 3-3 CON 3-4 Oven Temp Sensor CON 3-9 CON 3-10 Oven Light (K2)
  • Page 14 NOTES...
  • Page 15 EZ Control, Standard Clean, Gas Models: AGR4422VDB0 AGR4422VDD0 AGR4422VDS0 AGR4422VDW0 Temperature Adjustment Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed. ew Automated Process | Released Press TEMP/TIME of Adjusts temperature in 10⁰ F (5⁰ C) increments TEMP/HOUR "+"...
  • Page 16: W10155514

    Replace all parts and panels before operating. Caution: Label all wires prior to d Failure to do so can result in death or servicing controls. Wiring errors c electrical shock. Wiring Information TS# W10155514 dangerous operation. Verify proper operation after servi NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off.
  • Page 17 LCC Standard Clean, GAS LCC90 Control, Standard Clean, GAS Models: SF114PXSB2 SF114PXSQ2 SF114PXST2 SF114PXSW2 WFG114SVB0 WFG114SVQ0 WFG114SVT0 WFG114SVW0 WFG231LVB0 WFG231LVQ0 WFG231LVS0 LCC90 Control, Standard Clean, GAS Models: AGR4433XDB0 AGR4433XDS0 AGR4433XDW0 Temperature Adjustment 1. Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed. Temperature Adjustment Adjusts temperature in 10⁰...
  • Page 18: Wiring Diagrams

    Wiring Diagrams Wiring Information TS# W10200950 Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. NOTE: Schematic shows doors closed and relays off Failure/Error Display Codes DISPLAY LIKELY FAILURE CONDITION SUGGESTED CORRECTIVE ACTION PROCEDURE...
  • Page 19 LCC Self-Clean, Electric LCC95 Control, Self-Clean, Electric Models: WFE361LVB0 WFE361LVD0 WFE361LVQ0 WFE361LVS0 WFE361LVT0 YWFE361LVB0 YWFE361LVQ0 YWFE361LVS0 IVP33800 IVP85800 IVP85801 TES325VQ0 TES325VT0 LCC190 Control, Self-Clean, Electric Models: WFE364LVB0 WFE364LVD0 WFE364LVQ0 WFE364LVS0 WFE364LVT0 WFE366LVB0 WFE366LVQ0 WFE366LVS0 WFE366LVT0 YWFE366LVB0 YWFE366LVQ0 YWFE366LVS0 LCC190 Control, Self-Clean, Steam Clean, Electric Models: Reviewed by Genview Automated Process | Released WFE371LVB0...
  • Page 20 MER7662WB0 MER7662WB1 MER7662WQ1 MER7662WS0 MER7662WS1 MER7662WT0 MER7662WW0 MER7662WW1 YMER7662WB0 YMER7662WB1 YMER7662WS1 YMER7662WW0 YMER7662WW1 LCC95 6 Self-Clean, Electric Models: AER5522VAS0 AER5522VAW0 AER5522VCS0 AER5522VCW0 AER5822VCB0 AER5822VCS0 AER5822VCW0 LCC180 Control, Self-Clean, Electric Models: AER5830VAB0 AER5830VAD0 AER5830VAS0 a L. | Released AER5830VAW0 AER5844VAB0 AER5844VAD0...
  • Page 21 LCC Self-Clean, Electric (continued) Temperature Adjustment 1. Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed. Adjusts temperature in 10⁰ F (5⁰ C) increments 2. Press TEMP/TIME "+" or "-". between -30⁰F and +30⁰F. Bake and Broil Temperatures are offset automatically to the same degree.
  • Page 22: W10198585

    TS# W10198581 Wiring Information NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Quick Connect Plugs Connectors For controls For cooktop CON3 CON1 CON2 Right Side Left Side Cooktop Cooktop BK/W PIN 1 PIN 1 CON 1 CON 3...
  • Page 23 LCC Self-Clean, Gas LCC95 Control, Self-Clean, Gas Models: TGS325VB0 TGS325VB1 TGS325VQ0 TGS325VQ1 TGS325VT0 TGS325VT1 LCC190 Control, Self-Clean, Gas Models: WFG361LVB0 WFG371LVS0 WFG361LVB1 WFG371LVS1 WFG361LVD0 WFG374LVB0 WFG361LVD1 WFG374LVB1 WFG361LVQ0 WFG374LVD0 WFG361LVQ1 WFG374LVD1 WFG361LVS0 WFG374LVQ0 WFG361LVS1 WFG374LVQ1 WFG361LVT0 WFG374LVS0 WFG361LVT1 WFG374LVS1 WFG371LVB0 WFG381LVB0 WFG371LVB1 WFG381LVB1...
  • Page 24 LCC Self-Clean, Gas (continued) LCC190 Control, Self-Clean, Gas Models: MGR7662WB0 MGR7662WW1 MGR7665WB0 MGR7662WB1 MGR7665WB1 MGR7662WQ0 MGR7665WS0 MGR7662WQ1 MGR7662WS0 MGR7665WS1 MGR7665WW0 MGR7662WS1 MGR7665WW1 MGR7662WW0 LCC95 Control, Self-Clean, Gas Models: AGR5844VDB0 AGR5844VDS0 AGR5844VDB1 AGR5844VDS1 AGR5844VDB2 AGR5844VDS2 AGR5844VDD0 AGR5844VDW0 AGR5844VDD1 AGR5844VDW1 AGR5844VDD2 AGR5844VDW2 Temperature Adjustment 1.
  • Page 25: W10198635

    Wiring Diagram NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Wiring Information TS# W10198635 Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
  • Page 26 NOTES...
  • Page 27 LCC Control, Self Clean, Gas LCC190 Control, Self Clean, Gas Models: MGR8670WB0 MGR8670WB1 MGR8670WQ0 MGR8670WQ1 MGR8670WS0 MGR8670WS1 MGR8670WW0 MGR8670WW1 Temperature Adjustment Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed. Press TEMP/TIME or Adjusts temperature in 10⁰ F (5⁰ C) increments Press TEMP/TIME “+”...
  • Page 28 Wiring Diagram TE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Wiring Information TS# W10239472 Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off.
  • Page 29 LCC Control, Self Clean, Convection, Electric LCC190 Control, Self Clean, Convection, Steam Clean, Electric Models: WFE381LVB0 WFE381LVQ0 WFE381LVS0 YWFE381LVB0 YWFE381LVQ0 YWFE381LVS0 LCC190 Control, Self Clean, Convection, Electric Models: MER7765WB0 MER7765WB1 MER7765WS0 MER7765WS1 MER7765WW0 MER7765WW1 YMER7765WB0 YMER7765WB1 YMER7765WS0 YMER7765WS1 YMER7765WW0 YMER7765WW1 LCC190 Control, Self Clean, Convection, Steam Clean Electric wed by Staples, Debra L.
  • Page 30 LCC Control, Self Clean, Convection, Electric (continued) LCC190 Control, Self Clean, Convection, Electric Models: MER8770WB0 MER8770WQ0 MER8770WS0 MER8770WW0 YMERH770WB0 YMERH770WB1 YMERH770WS0 YMERH770WS1 YMERH770WW0 YMERH770WW1 LCC190 Control, Self-Clean, Convection, Electric Models: AER6011VAB0 AER6011VAS0 AER6011VAW0 Temperature Adjustment Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed.
  • Page 31: W10198581

    Wiring Information TS# W10198584 Wiring Diagram NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. W/BU W/BU W/BU...
  • Page 32 NOTES...
  • Page 33 LCC Self Clean, Convection, Gas LCC190 Control, Self Clean, Convection, Gas Models: MGR7775WB0 MGR7775WB1 MGR7775WS0 MGR7775WS1 MGR7775WW0 MGR7775WW1 LCC190 Control, Self-Clean, Convection, Gas Models: AGR6011VDB0 AGR6011VDB1 AGR6011VDS0 AGR6011VDS1 AGR6011VDW0 AGR6011VDW1 Temperature Adjustment Press BAKE for 5 seconds. Previous Offset shown, or U-00 is displayed. Temperature Adjustment Press TEMP/TIME or Adjusts temperature in 10⁰...
  • Page 34 Wiring Diagram NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. TS# W10198636 Wiring Information Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
  • Page 35 LCC Fault Code Procedure Eletrical Shock Hazard Electrical Shock Hazard CLr/Good - Control is good do not replace • Verify voltage at power supply. No Display - Control Blank • Verify voltage between control board and terminal block by completing the following steps: 1.
  • Page 36 LCC Fault Code Procedure (continued) All F1 E* Codes (Control) • Run Diagnostic Mode and verify fault code • Unplug range or disconnect power. • Replace Control • Run Diagnostic Mode and verify F2 Fault Code (Stuck Key on Control) fault code •...
  • Page 37 LCC Fault Code Procedure (continued) • Run Diagnostic Mode and verify F5 E1 (Door Latch Switch) fault code • While in Diagnostic Mode - Start Clean cycle, to verify door does latch. • Unplug range or disconnect power. If door did not latch - check for contunity at CON3-4 to CON3-1 •...
  • Page 38 NOTES...
  • Page 39 MRC Convection, Electric MRC Control, True Convection, Steam Clean, Electric Models: GFE461LVB0 GFE461LVQ0 GFE461LVS0 GFE461LVT0 YGFE461LVB0 YGFE461LVQ0 YGFE461LVS0 MRC Control, True Convection, Warming Drawer, Steam Clean, Electric Models: GFE471LVB0 GFE471LVQ0 GFE471LVS0 YGFE471LVB0 YGFE471LVQ0 YGFE471LVS0 Temperature Adjustment 1. Press "BAKE" for 5 seconds. Previous Offset shown, or U-00 is displayed.
  • Page 40 MRC Convection, Electric (continued) MRC Control, Fan Convection, Electric Models: MER8772WB0 YMER8772WS1 MER8772WB1 YMER8772WW0 MER8772WS0 YMER8772WW1 MER8772WS1 YMERH770WB0 MER8772WW0 YMERH770WB1 MER8772WW1 YMERH770WS0 YMER8772WB0 YMERH770WS1 YMER8772WB1 YMERH770WW0 YMER8772WS0 YMERH770WW1 MRC Control, True Convection, Electric Models: YMER8875WB0 MER8875WB0 YMER8875WB1 MER8875WB1 YMER8875WS0 MER8875WS0 YMER8875WS1 MER8875WS1 YMER8875WW0...
  • Page 41 Wiring Information TS# W10198586 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Wiring Diagram NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. P6-5 Oven Control MRC FOR SERVICE TECHNICIAN’S USE ONLY...
  • Page 42 NOTES...
  • Page 43 MRC Convection, Gas MRC Control, Convection, Gas Models: GFG461LVT0 GFG461LVB0 GFG461LVB1 GFG461LVT1 GFG461LVB2 GFG461LVT2 GFG461LVQ0 GFG464LVB0 GFG464LVB1 GFG461LVQ1 GFG464LVQ0 GFG461LVQ2 GFG464LVQ1 GFG461LVS0 GFG461LVS1 GFG464LVS0 GFG461LVS2 GFG464LVS1 MRC Control, Convection, Warming Drawer, Gas Models: GFG471LVB0 GFG471LVB1 GFG471LVQ0 GFG471LVQ1 GFG471LVS0 GFG471LVS1 Temperature Adjustment 1.
  • Page 44: W10208861

    Wiring Diagram Wiring Information TS# W10208861 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Caution: Label all wires prior to disconnection when servicing controls.
  • Page 45 MRC Convection, Gas (continued) MRC Control, Convection, Gas Models: MGR8772WB0 MGR8772WS0 MGR8772WW0 MGR8875WB0 MGR8875WB1 MGR8875WS0 MGR8875WS1 MGR8875WW0 MGR8875WW1 Temperature Adjustment Press "OVEN LIGHT" for 5 seconds. Previous Offset shown, or U-00 is displayed. Adjusts temperature in 5⁰F (3⁰C) increments Press TEMP/TIME "+" or "-". between -30⁰F (-18⁰C) and +30⁰F (+18⁰C).
  • Page 46: W10239474

    NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Wiring Information TS# W10239474 Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off.
  • Page 47 MRC Fault Code Procedure Eletrical Shock Hazard Electrical Shock Hazard No Faults - Control is good do not replace Do Not Replace Control • Verify 120VAC between P6-1 No Display - Control is blank to P6-3 by completing the following steps: 1.
  • Page 48 MRC Fault Code Procedure (continued) All F1 E* Codes (Control) • Run Diagnostic Mode and go to "Faults" display • Verify fault code • Unplug range or disconnect • power. • Replace Control F2 Fault Code (Stuck Key on Control) •...
  • Page 49 MRC Fault Code Procedure (continued) F5 E0 (Door Switch) • Run Diagnostic Mode and go to “Faults” display • Verify fault code • Unplug range or disconnect power. • Check for continuity with door open and door closed at P7-4 to P7-5 •...
  • Page 50 MRC Fault Code Procedure (continued) All F6 E* (Control Communication) • Run Diagnostic Mode and verify fault code • Unplug range or disconnect power. • Replace Control All F9 Fault Codes (House Miswired) • Run Diagnostic Mode and verify fault code •...
  • Page 51 Notes...
  • Page 52 MRC II Double Oven, Electric MRC II Control, Double Oven, Warming Zone, Electric Models: GGE388LXB00 GGE388LXQ00 GGE388LXS00 MRC II Control, Double Oven, True Convection (Lower) Warming Zone, Electric Models: GGE390LXB00 GGE390LXQ00 GGE390LXS00 MRC II Control, Double Oven, Warming Zone, Electric Models: MET8665XB00 MET8665XS00...
  • Page 53 MRC II Double Oven, Electric (continued) MRC II Control, Double Oven, Fan Convection (Lower) Warming Zone, Electric Models: MET8775XB00 MET8775XS00 MET8775XW00 MRC II Control, Double Oven, True Convection (Lower) Warming Zone, Electric Models: MET8885XB00 MET8885XS00 MET8885XW00 YMET8885XB00 YMET8885XS00 Temperature Adjustment YMET8885XW00 Press "SETTINGS"...
  • Page 54 Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Wiring Information TS# W10311747 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. ...
  • Page 55 MRC II Double Oven, Electric (continued) MRC II Control, Double Oven, True Convection (Lower) Warming Zone, Electric Models: KERS505XBL00 KERS505XSS00 KERS505XWH00 MRC II Control, Double Oven, True Convection (Lower) Warming Zone, Electric Models: Released KERS507XSS00 YKER507XSS00 Temperature Adjustment Press "OPTIONS" until "Temp Calib" Previous Offset shown.
  • Page 56 MRC II Control, Double Oven, True Convection (Lower), Dual Fuel MRC II Control, Double Oven, True Convection (Lower), Dual Fuel Models: KDRS505XSS00 Temperature Adjustment Press "OPTIONS" until "Temp Calib" Previous Offset shown. is displayed. Adjusts temperature in 5⁰F (3⁰C) increments Press #3 or #6 keypads.
  • Page 57: W10323649

    FOR SERVICE TECHNICIAN’S USE ONLY Wiring Diagram Wiring Information TS# W10323649 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Control Board Sensor Sensor...
  • Page 58 MRC II Double Oven, Gas MRC II Control, Double Oven, Gas Models: GGG388LXB00 GGG388LXQ00 GGG388LXS00 Temperature Adjustment Press "SETTINGS" until "Temp Calib" Previous Offset shown, or U-00 is displayed. is displayed. Adjusts temperature in 5⁰F (3⁰C) increments Press TEMP/TIME "+" or "-". between -30⁰F (-18⁰C) and +30⁰F (+18⁰C).
  • Page 59: W10311747

    TS# W10311742 Wiring Information NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. FOR SERVICE TECHNICIAN’S USE ONLY Quick Connect Plugs Connectors For controls FOR SERVICE TECHNICIAN’S USE ONLY P10 (Yellow) P5 (Blue) P7 (Black) Quick Connect Plugs For controls...
  • Page 60 MRC II Control, Double Oven, Gas, (continued) MRC II Control, Double Oven, True Covection (Lower), Gas Models: GGG390LXB00 GGG390LXQ00 GGG390LXS00 MRC II Control, Double Oven, Fan Convection (Lower), Gas Models: MGT8655XB00 MGT8655XS00 MGT8655XW00 MRC II Control, Double Oven, Fan Convection (Lower), Gas Models: MGT8775XB00 MGT8775XS00...
  • Page 61 MRC II Double Oven, Gas MRC II Control, Double Oven, True Convection (lower), Gas Models: MGT8885XB00 MGT8885XS00 MGT8885XW00 Temperature Adjustment Press "SETTINGS" until "Temp Calib" Previous Offset shown, or U-00 is displayed. is displayed. Adjusts temperature in 5⁰F (3⁰C) increments Press TEMP/TIME "+"...
  • Page 62: W10311752

    Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and Wiring Information dangerous operation. Verify proper operation after servicing. TS W10311752 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Oven Control MRC II Power Supply Lower Door Position Switch...
  • Page 63 Notes...
  • Page 64 MRC II Double Oven, True Convection (Lower), Gas MRC II Control, Double Oven, True Convection (Lower), Gas Models: KGRS505XBL00 KGRS505XSS00 KGRS505XWH00 Temperature Adjustment Press "OPTIONS" until "Temp Calib" Previous Offset shown. is displayed. Adjusts temperature in 5⁰F (3⁰C) increments Press #3 or #6 keypads. between -30⁰F (-18⁰C) and +30⁰F (+18⁰C).
  • Page 65 Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Wiring Information TS# W10311752 NOTE: Schematic shows door latch switch in the COOK position with oven door open and elements off. Power Supply Lower Door Position Switch BU/W...
  • Page 66 MRC II Fault Code Procedure Eletrical Shock Hazard Electrical Shock Hazard Do Not Replace Control No Faults - Control is good do not replace No Display - Control blank • Verify voltage at power supply. • Verify voltage between control board pins P6-1 and P6-3 by completing the following steps: 1.
  • Page 67 MRC II Fault Code Procedure (continued) All F1 E* Codes (Control) • Run Diagnostic Mode and verify • fault Code • Unplug range or disconnect power • Replace Control F2 Fault Code (Stuck Key on Control) • Run Diagnostic Mode and verify fault Code •...
  • Page 68 MRC II Fault Code Procedure (continued) • Run Diagnostic Mode and verify F5 E0 (Door Switch) fault code • Unplug range or disconnect power • Check door switch for continuity with door open and door closed : Upper Oven at P7-4 to P7-5. Lower Oven P7-4 to P7-6.
  • Page 69 MRC II Fault Code Procedure (continued) F5 E1 (Door Latch System) • Run Diagnostic Mode and verify fault code • While in Diagnostic Mode - Start Clean cycle, to verify that door does latch. • Unplug range or disconnect power •...
