8.2 General Specifications

Protection and features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips in case of overtem-
perature.
•
The adjustable frequency drive is protected against short-circuits between motor terminals U, V, W.
•
When a motor phase is missing, the adjustable frequency drive trips and issues an alarm.
•
When a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips when the
intermediate circuit voltage is too low or too high.
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
Line power supply (L1, L2, L3)
Supply voltage
Supply voltage
8 8
Supply voltage
Supply frequency
Max. temporary imbalance between line phases
True Power Factor (λ)
Displacement Power Factor (cosφ) near unity
Switching on the input supply L1, L2, L3 (power-ups) enclosure frame H1-H5, I2, I3, I4
Switching on the input supply L1, L2, L3 (power-ups) enclosure frame H6-H8, I6-I8
Environment according to EN 60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/480 V
maximum.
Motor output (U, V, W)
Output voltage
Output frequency
Switching on output
Ramp times
Cable lengths and cross-sections
Max. motor cable length, shielded/armored (EMC-compatible installation)
Max. motor cable length, non-shielded/unarmored
Max. cross-section to motor, line power*
Cross-section DC terminals for filter feedback on enclosure frame H1-H3, I2, I3, I4
Cross-section DC terminals for filter feedback on enclosure frame H4-H5
Maximum cross-section to control terminals, rigid wire
Maximum cross-section to control terminals, flexible cable
Minimum cross-section to control terminals
*See chapter 8.1.2 Line Power Supply 3x380–480 V AC for more information.
114
Design Guide
Danfoss A/S © Rev. 2014-01-14 All rights reserved.
200–240 V ±10%
380–480 V ±10%
525–600 V ±10%
3.0% of rated supply voltage
≥ 0.9 nominal at rated load
Max. 2 times/min.
Max. 1 time/min.
overvoltage category III/pollution degree 2
0–100% of supply voltage
plus
0–200 Hz (VVC ), 0–400 Hz (u/f)
See chapter 2.8.2 EMC Test Results
4 mm
16 mm
2.5 mm
2.5 mm
0.05 mm
50/60 Hz
(>0.98)
Unlimited
0.05–3600 s
50 m
2
/11 AWG
2
/6 AWG
2 /14 AWG)
2
/14 AWG)
2
/30 AWG
