8.1.3 Line Power Supply 3x380–480 V AC
Adjustable frequency drive
Typical shaft output [kW]
Typical shaft output [hp]
IP54 frame
Max. cable size in terminals (line power, motor)
[mm 2 /AWG]
Output current
104 °F [40 °C] ambient temperature
Continuous (3x380–440 V) [A]
Intermittent (3x380–440 V) [A]
Continuous (3x440–480 V) [A]
Intermittent (3x440–480 V) [A]
Max. input current
Continuous (3x380-440 V) [A]
Intermittent (3x380–440 V) [A]
Continuous (3x440–480 V) [A]
Intermittent (3 x 440–480 V) [A]
Max. electrical fuses
Estimated power loss [W], Best case/typical
Weight enclosure IP54 [kg]
Efficiency [%], Best case/Typical 1)
Output current
122 °F [50 °C] ambient temperature
Continuous (3x380–440 V) [A]
Intermittent (3x380–440 V) [A]
Continuous (3x440–480 V) [A]
Intermittent (3x440–480 V) [A]
Table 8.6 PK75–P15K
1) At rated load conditions
MG18C522
Design Guide
PK75 P1K5 P2K2
0.75 1.5 2.2
1.0 2.0 3.0
I2 I2 I2
4/10 4/10 4/10
2.2 3.7 5.3
2.4 4.1 5.8
2.1 3.4 4.8
2.3 3.7 5.3
2.1 3.5 4.7
2.3 3.9 5.2
1.8 2.9 3.9
2.0 3.2 4.3
See chapter 5.2.3 Fuses and Circuit Breakers
1) 21/ 46/ 46/
16 57 58
0.21 0.21 0.21
[5.3] [5.3] [5.3]
98.0/ 97.7/ 98.3/
97.6 97.2 97.9
1.93 3.7 4.85
2.1 4.07 5.4
1.8 3.4 4.4
2.0 3.7 4.8
Danfoss A/S © Rev. 2014-01-14 All rights reserved.
P3K0 P4KO P5K5 P7K5
3.0 4.0 5.5 7.5
4.0 5.0 7.5 10.0
I2 I2 I3 I3
4/10 4/10 4/10 4/10
7.2 9.0 12.0 15.5
7.9 9.9 13.2 17.1
6.3 8.2 11.0 14.0
6.9 9.0 12.1 15.4
6.3 8.3 11.2 15.1
6.9 9.1 12.3 16.6
5.3 6.8 9.4 12.6
5.8 7.5 10.3 13.9
66/ 95/ 104/ 159/
83 118 131 198
0.21 0.21 15.87 15.87
[5.3] [5.3] [7.2] [7.2]
98.2/ 98.0/ 98.4/ 98.2/
97.8 97.6 98.0 97.8
6.3 7.5 10.9 14.0
6.9 9.2 12.0 15.4
5.5 6.8 10.0 12.6
6.1 8.3 11.0 13.9
P11K P15K
11 15
15 20
I4 I4
16/6 16/6
23.0 31.0
25.3 34.0
21.0 27.0
23.1 29.7
22.1 29.9
24.3 32.9
18.4 24.7
8 8
20.2 27.2
248/ 353/
274 379
30.42 30.42
[13.8] [13.8]
98.1/ 98.0/
97.9 97.8
20.9 28.0
23.0 30.8
19.1 24.0
21.0 26.4
