8.5 Derating according to Ambient Temperature and Switching Frequency

The ambient temperature measured over 24 hours should be at least 9 °F [5 °C] lower than the max. ambient temperature.
If the adjustable frequency drive is operated at a high ambient temperature, the continuous output current should be
decreased.
8 8
I [%]
out
110%
100%
90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
10 %
0
0 2
Figure 8.1 200 V IP20 H1 0.34–1 hp [0.25–0.75 kW]
I [%]
out
110%
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
0
0 2
Figure 8.2 400 V IP20 H1 0.5–2 hp [0.37–1.5 kW]
