Danfoss VLT HVAC Basic Drive FC 101 Design Manual page 118

General Specifications and ...
Control card, 24 V DC output
Terminal number
Max. load
Relay output
Programmable relay output
Relay 01 and 02
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
(NC) (Resistive load)
Environment according to EN 60664-1
1)
IEC 60947 parts 4 and 5.
Control card, 10 V DC output
8 8
Terminal number
Output voltage
Max. load
A)
All inputs, outputs, circuits, DC supplies and relay contacts are galvanically isolated from the supply voltage (PELV) and
other high-voltage terminals.
Surroundings
Enclosure
Enclosure kit available.
Vibration test
Max. relative humidity
Aggressive environment (IEC 60721-3-3), coated (standard) frame H1-H5
Aggressive environment (IEC 60721-3-3), non-coated frame H6-H10
Aggressive environment (IEC 60721-3-3), coated (optional) frame H6-H10
Aggressive environment (IEC 60721-3-3), non-coated frame I2–I8
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature
Derating for high ambient temperature, see chapter 8.5 Derating according to Ambient Temperature and Switching
Frequencychapter 8.5 Derating according to Ambient Temperature and Switching Frequency.
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Derating for high altitude, see
Safety standards
EMC standards, Emission
EMC standards,
Immunity
116
Design Guide
1)
on 01-02/04-05 (NO) (Resistive load)
1)
on 01-02/04-05 (NO) (Inductive load @ cosφ 0.4)
1) on 01-02/04-05 (NO) (Resistive load)
1)
on 01-02/04-05 (NO) (Inductive load)
1)
on 01-03/04-06 (NC) (Resistive load)
1)
on 01-03/04-06 (NC) (Inductive load @ cosφ 0.4)
1) on 01-03/04-06
Min. terminal load on 01-03 (NC), 01-02 (NO) 24 V DC 10 mA, 24 V AC 20 mA
A)
See max. output current at 104/122 °F [40/50 °C] in chapter 8.1.2 Line Power Supply 3x380–480 V AC
EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
Danfoss A/S © Rev. 2014-01-14 All rights reserved.
01-03 (NC), 01-02 (NO), 04-06 (NC), 04-05 (NO)
Overvoltage category III/pollution degree 2
5%–95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
24 V DC, 0.1 A
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
10.5 V ±0.5 V
IP21, TYPE 1
Class 3C3
Class 3C2
Class 3C3
Class 3C2
32 °F [0 °C]
-4 °F [-20 °C]
14 °F [-10 °C]
-22 to +149/158 °F [-30 to +65/70 °C]
3,300 ft [1000 m]
10,000 ft [3000 m]
EN/IEC 61800-5-1, UL 508C
61000-4-5, EN 61000-4-6
MG18C522
12
80 mA
2
50
25 mA
IP20
1.0 g
