Multirack Cabling Diagrams For Exalogic-To-Exadata Scenarios; Connecting An Exalogic Eighth Rack And An Exadata Quarter Rack - Oracle Exalogic EL X2-2 Multirack Cabling Manual

B
Multirack Cabling Diagrams for Exalogic-to-
Exadata Scenarios
This appendix contains multirack cabling diagrams for the Exalogic-to-Exadata
scenarios listed in
Table B-1
Exalogic
Machine
Rack Type
1/8
1/8
1/8
1/4
1/4
1/4
1/2
1/2
1/2
Full
Full
Full
B.1 Connecting an Exalogic Eighth Rack and an Exadata
Quarter Rack
Figure B-1
connected on the same InfiniBand fabric.
Table B-1.
Exalogic-to-Exadata Multirack Cabling Scenarios
Exadata Section
Database
Machine
Rack Type
1/4 Connecting an Exalogic Eighth Rack and an Exadata Quarter
Rack
1/2 Connecting an Exalogic Eighth Rack and an Exadata Half Rack
Full Connecting an Exalogic Eighth Rack and an Exadata Full Rack
1/4 Connecting an Exalogic Quarter Rack and an Exadata Quarter
Rack
1/2 Connecting an Exalogic Quarter Rack and an Exadata Half Rack
Full Connecting an Exalogic Quarter Rack and an Exadata Full Rack
1/4 Connecting an Exalogic Half Rack and an Exadata Quarter Rack
1/2 Connecting an Exalogic Half Rack and an Exadata Half Rack
Full Connecting an Exalogic Half Rack and an Exadata Full Rack
1/4 Connecting an Exalogic Full Rack and an Exadata Quarter Rack
1/2 Connecting an Exalogic Full Rack and an Exadata Half Rack
Full Connecting an Exalogic Full Rack and an Exadata Full Rack
illustrates how an Exalogic eighth rack and an Exadata quarter rack are
B-1
