A
Multirack Cabling Diagrams for Exalogic-to-
Exalogic Scenarios
This appendix contains multirack cabling diagrams for the following scenarios:
• One Exalogic machine with another Exalogic machine, as listed in
• Eight Exalogic machines, as described in
Table A-1
Exalogic
Machine
Rack Type
1/8
1/8
1/8
1/8
1/4
1/4
1/4
1/2
1/2
Full
A.1 Connecting Two Exalogic Eighth Racks
Figure A-1
InfiniBand fabric.
Exalogic-to-Exalogic Multirack Cabling Scenarios
Exalogic Section
Machine Rack
Type
1/8

Connecting Two Exalogic Eighth Racks

1/4 Connecting an Exalogic Eighth Rack and Exalogic Quarter
Rack
1/2 Connecting an Exalogic Eighth Rack and Exalogic Half Rack
Full Connecting an Exalogic Eighth Rack and Exalogic Full Rack
1/4 Connecting Two Exalogic Quarter Racks
1/2 Connecting an Exalogic Quarter Rack and an Exalogic Half
Rack
Full Connecting an Exalogic Quarter Rack and an Exalogic Full
Rack
1/2 Connecting Two Exalogic Half Racks
Full Connecting an Exalogic Half Rack and an Exalogic Full Rack
Full Connecting Two Exalogic Full Racks
illustrates how two Exalogic eighth racks are connected on the same
Table
Connecting Eight Exalogic Full
A-1.
Racks.
A-1
