5.2.2.4 Connect Each Leaf Switch in One Exalogic Rack to Spine Switches in
the Other Exalogic Rack
Table 5-3
switches (NM2-GW) from each Exalogic machine full rack to the spine switches
(NM2-36P) in the other Exalogic machine full rack. The 5-meter cables are bundled
with the Exalogic machine.
Table 5-3
Rack's Spine Switch
Cable Coming from
Slot
R1-U26
R1-U26
R1-U26
R1-U26
R1-U24
R1-U24
R1-U24
R1-U24
R1-U23
R1-U23
R1-U23
R1-U23
R1-U16
R1-U16
R1-U16
R1-U16
For network connectivity diagrams of other Exalogic-to-Exalogic scenarios, see
Multirack Cabling Diagrams for Exalogic-to-Exalogic Scenarios
lists the 5-meter cables (or longer) that should be used to connect leaf
Connect 5-Meter Cable One Rack's Leaf Switches to the Second
Port
2A
2B
3A
3B
2A
2B
3A
3B
2A
2B
3A
3B
2A
2B
3A
3B
Note:
Connect leaf switches in each Exalogic machine full rack to the spine switch in
the other Exalogic machine full rack, as shown in
Connecting Two Exalogic Machine Full Racks Together
Connecting to Slot Port
R2-U1 9A
R2-U1 9B
R2-U1 10A
R2-U1 10B
R2-U1 11A
R2-U1 11B
R2-U1 12A
R2-U1 12B
R2-U1 13A
R2-U1 13B
R2-U1 14A
R2-U1 14B
R2-U1 15A
R2-U1 15B
R2-U1 16A
R2-U1 16B
Table
Chapter 5
Length
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5 meter
5-3.
.
