Connecting Two Exalogic Machines

This chapter describes how to connect two Exalogic machines on the same InfiniBand
fabric.
It includes the following topics:
•

Before You Begin

•

Connecting Two Exalogic Machine Full Racks Together

5.1 Before You Begin
Before you start connecting multiple Exalogic machines together, ensure that you have
completed all of the multirack cabling tasks described in
5.2 Connecting Two Exalogic Machine Full Racks Together
This section discusses how to connect two Exalogic machine full racks together. It
contains the following topics:
•

Connectivity Diagram

• Connect Two Exalogic Machine Full Racks Together
5.2.1 Connectivity Diagram
Figure 5-1
machine full rack.
shows how an Exalogic machine full rack is connected to another Exalogic
Multirack Cabling Tasks.
