Removing Factory-Installed Cables (Cross-Connects) In Exalogic Machine Full Rack; Factory-Installed Cross-Connects In Exalogic Machine To Be Removed - Oracle Exalogic EL X2-2 Multirack Cabling Manual

Removing Factory-Installed Cables (Cross-Connects) in Exadata Database
2.
Machine Full Rack
Connecting Each Leaf Switch in Exalogic Machine Full Rack to Its Spine Switch
3.
Connecting Each Leaf Switch in Exadata Database Machine Full Rack to Its Spine
4.
Switch
Connecting Exalogic Leaf Switches to Spine Switch of Exadata Database Machine
5.
Connecting Leaf Switches of Exadata Database Machine to Spine Switch of
6.
Exalogic Machine
6.2.2.1 Removing Factory-Installed Cables (Cross-Connects) in Exalogic
Machine Full Rack
Table 6-1
should be removed.
The system naming conventions are as follows. "R" indicates an Exalogic machine
rack. For example, R1 indicates rack 1. "U" indicates the unit height in the rack. For
example, U24 indicates rack unit 24. U1 is located at the bottom of the rack, and U42
is at the top of the rack. For more information about Exalogic machine rack layout, see
the Oracle Exalogic Elastic Cloud Machine Owner's Guide.
Table 6-1
Removed
Cable Coming from
Slot (Exalogic
Machine)
R1-U16
R1-U16
R1-U16
R1-U16
R1-U16
R1-U16
R1-U16
R1-U16
R1-U23
R1-U23
R1-U23
R1-U23
R1-U23
R1-U23
Connecting an Exalogic Machine Full Rack and an Exadata Database Machine Full Rack
lists the factory-installed Exalogic machine cross-connects (cables) that
Factory-Installed Cross-Connects in Exalogic Machine to be
Port
0A
0B
1A
1B
2A
2B
3A
3B
0A
0B
1A
1B
2A
2B
Connecting to Slot Port
(Exalogic Machine)
R1-U26 0A
R1-U26 0B
R1-U26 1A
R1-U26 1B
R1-U24 2A
R1-U24 2B
R1-U24 3A
R1-U24 3B
R1-U24 0A
R1-U24 0B
R1-U24 1A
R1-U24 1B
R1-U26 2A
R1-U26 2B
Chapter 6
Length
2 meter
2 meter
2 meter
2 meter
2 meter
2 meter
2 meter
2 meter
1 meter
1 meter
1 meter
1 meter
1 meter
1 meter
6-3
