Appendix A
Connecting Eight Exalogic Full Racks
Figure A-10
Two Exalogic Full Racks
In
Figure
A-10, NM2-GW represents a Sun Network QDR InfiniBand Gateway Switch
(leaf switches). NM2-36P represents a Sun Datacenter InfiniBand Switch 36 (spine
switch).
This scenario is explained in detail in
Connecting Two Exalogic Machine Full Racks
Together. It is included in this appendix for the sake of completeness.
A.11 Connecting Eight Exalogic Full Racks
Figure A-11
illustrates how eight Exalogic full racks are connected on the same
InfiniBand fabric.
