5.2.2.1 Remove the Factory-Installed Cables

Table 5-1
should be removed. Remove these cables in each of the Exalogic machine full racks
that will be connected on the same InfiniBand fabric.
The system naming conventions are as follows. "R" indicates an Exalogic machine
rack or an Exadata Database Machine rack. For example, R1 indicates rack 1. "U"
indicates the unit height in the rack. For example, U24 indicates rack unit 24. U1 is
located at the bottom of the rack, and U42 is at the top of the rack. For more
information about Exalogic machine rack layout, see the Oracle Exalogic Elastic Cloud
Machine Owner's Guide.
Table 5-1
Cable Coming from
Slot
U16
U16
U16
U16
U16
U16
U16
U16
U23
U23
U23
U23
U23
U23
U23
U23
lists the factory-installed Exalogic machine cross-connects (cables) that

Remove Factory-Installed Cross-Connects in Exalogic Machines

Port
0A
0B
1A
1B
2A
2B
3A
3B
0A
0B
1A
1B
2A
2B
3A
3B
Note:
Remove the factory-installed cables as shown in
machines.
Connecting Two Exalogic Machine Full Racks Together
Connecting to Slot Port
U26 0A
U26 0B
U26 1A
U26 1B
U24 2A
U24 2B
U24 3A
U24 3B
U24 0A
U24 0B
U24 1A
U24 1B
U26 2A
U26 2B
U26 3A
U26 3B
Table 5-1
Chapter 5
Length
2 meter
2 meter
2 meter
2 meter
2 meter
2 meter
2 meter
2 meter
1 meter
1 meter
1 meter
1 meter
1 meter
1 meter
1 meter
1 meter
from both Exalogic
5-3
