3.3 Performing a Cable Inventory

Collect and inventory the cables you ordered, if any. You should inventory spare
cables from the kit and the existing multirack cables. Each Exalogic machine includes
a kit of spare parts.
Some spare cables are used for multirack cabling. The following table lists the spare
cables available for the switch, and their length.
No additional InfiniBand cables need to be purchased when connecting an Exalogic
machine full rack with another Exalogic machine full rack or with an Exadata Database
Machine. The 5-meter cables provided in the spares kit with each Exalogic machine
can be used for making the connections.
You can use some cables in the spare parts pool for multirack cabling.

3.4 Gathering the Required Tools

Gather the following tools:
• Pen
• Notepad
• Flashlight
• Magnifying glass
• Label maker and labels (for cables, KVM console, and rack)
• Cable ties (hook-and-loop straps suggested)
Note:
For Exalogic machine full racks, 16 QSFP passive copper cables of length 5
meter, with part number 594-6387-01, are included in the spare kit. These
cables are intended for multirack cabling.
